VisuNet FLX System
Mechanical Installation
4.6

Open the Housing

Opening the VisuNet FLX System AG-3200-* Housing
1.
Remove the 4 threaded sleeves from the back of the housing.
2.
Remove the DPU from the housing and carefully lock the retaining feet on the lower part of the
housing into the brackets provided.
3.
Slowly lower the DPU.
4.
Hook the housing cover into the upper side of the housing. Make sure that both sides are
hooked in. Make sure that the hooks are engaged in the same was as in figure 4.9.
35
