VisuNet FLX System
Installing Peripherals
10.
Connect the plug of the barcode reader connection cable or base station connection cable to
the M12 connector of the adapter and tighten it firmly.
Figure 7.21
Coded Plug and Socket
Figure 7.22
The plug and socket are coded. Match the coding on the plug and socket before
tightening.
Note
For further information regarding the IDM Zone 2/22 barcode reader portfolio
refer to the IDM barcode reader manuals.
99
