Hardware Installation and Reference Guide
Silkscreen
Label
1F to 24F
25F to 26F
4. Technical Specifications
Table 1-15 Technical Specifications
Class
Physical
characteristics
Ports
Power supply
Reliability
1.5

Power Modules

The smart power modules for the RG-S6510-4C support power consumption management and hot swapping.
They can obtain the output power, output current, and operating temperature in real time.
Caution

To improve system stability and availability, you are advised to configure 1+1 power redundancy. The
chassis configured with power redundancy works in current-sharing mode.

At least one power module is required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.

Unplug the power cord before installing or removing the power module.
LED Description
Solid green: The port has made a successful link.
SFP28 port
Blinking green: The port is sending and receiving traffic.
LED
Off: No link is detected for the port.
LED for the 100GE/40GE port:
○
○
QSFP28 port
○
LED
LED for the four 25GE/10GE ports split from a 100GE port:
○
○
○
Item Specification
Dimensions (W x
D x H)
Weight Net weight: 0.5 kg (1.10 lbs.)
Port density
16 x 40GE QSFP+ ports
Max. power
99 W
consumption
Hot swapping Supported
Solid green: The port has made a successful 40/100 Gbps link.
Blinking green: The port is sending and receiving traffic at 40/100
Gbps.
Off: No 40/100 Gbps link is detected for the port.
Solid green: The port has made a successful 10/25 Gbps link.
Blinking green: The port is sending and receiving traffic at 10/25
Gbps.
Off: No 10/25 Gbps link is detected for the port.
Without packing materials: 207 mm x 165 mm x 41 mm (8.15 in. x
6.50 in. x 1.61 in.)
With packing materials: 465 mm x 335 mm x 312 mm (18.31 in. x
13.19 in. x 12.28 in.)
14
