Hardware Installation and Reference Guide
Consumption
Certificate
Operating
Temperature
Storage
Temperature
Operating
Humidity
MTBF
Weight
Dimension
(W x D x H)
2.2

Power Supply Modules

2.2.1 RG-PA300I-FS
Appearance
Module
Figure 2-8 Appearance of the RG-PA300I-FS Module
Ports
The RG-PA300I-FS module provides 12 V AC input to the RG-NBS7003 switch. The front panel of the power
supply module provides a 3-pin connector, which can be connected to a standard 10 A power cord.
CE
0° C to 50° C (32° F to 122° F)
–40° C to +70° C (–40° F to +158° F)
10% to 90% RH (non-condensing)
Over 200,000 hours
Net weight: 1.75 kg (3.86 lbs)
438.5 mm x 196 mm x 40.2 mm (17.26 in. x 7.72 in. x 1.58 in.)
21
