Installing Power Modules - Ruijie RGOS 11.X Installation Manual

Hardware Installation
Preparations

Installing Power Modules

All the chassis models have power module
slots at two sides of the chassis.
Precautions:
1. Ensure that there are no objects, such
as a PDU, near the rear mounting rails
within depth of the chassis in the cabinet
to hinder installation or removal of power
modules.
2. Each power module has a locking latch.
After connecting a power cable to a
power module, close the locking latch
to secure the power cable.
Installing the
Chassis to a
Specified Position
Two columns of
power modules
Installing Power
Grounding
Modules or Cards
Checking
