No. Component
5 Console port
6 Mini-USB port
7 Management port LED
8 Locating LED
9 System status LED
10 Reserved LED
11 Asset tag
12 Grounding stud
13 Power module slot
1.3.2

LEDs

Table 1-5 LEDs
Silkscreen
Label
Status
ID
LINK/ACT
LED Description
○
Status LED
○
○
Locating LED
Management
port LED
Solid green: The system is operating normally.
Blinking green: The system is starting up.
Solid red:
The system (including all modules) is not functioning properly.
Less than two fan modules are installed.
The temperature exceeds the limit and the switching service resets.
Off: The system is not receiving power or not operating even after
receiving power.
Solid blue: Locating is enabled.
Off: Locating is disabled (default).
Solid yellow: The port has made a successful 10/100 Mbps link.
Blinking yellow: The port is sending and receiving traffic at 10/100
Mbps.
Solid green: The port has made a successful 1,000 Mbps link.
Blinking green: The port is sending and receiving traffic at 1,000
Mbps.
Off: No link is detected for the port.
