Hardware Installation and Reference Guide
Class
Cooling
Reliability
Certification
Warning

Operation of this equipment in a residential environment could cause radio interference.

This equipment is not suitable for use in locations where children are likely to be present.

This equipment should be installed in the equipment room. Only a skilled person should be allowed to
install, replace, or service this equipment. Do not open the enclosure when the equipment is running. Cut
off the power supply before opening the enclosure in case of an electric shock.
1.3.6

Asset Tag

The asset tag is in the lower right corner of the rear panel. The tag can be pulled out of the panel. You can add
your own asset tracking label without interfering with the intended air flow.
Item
DC input
Max. output power
consumption
Airflow direction
Cooling mode
Fan type
Mean Time to
Recovery (MTTR)
Power redundancy
Fan redundancy
Hot swapping
EMC
Safety standard
Environment protection
Specification
RG-PA800I-F:
○ HVDC range: 180 V DC to 310 V DC
○ Rated voltage: 240 V DC
○
Max current: 5 A
RG-PD800I-F:
Rated voltage range: –36 V DC to –72 V DC
○
Rated voltage: –48 V DC
○
○
Max. current: 23 A
RG-PA800I-F: 800 W
RG-PD800I-F:
600 W (–36 V DC to –41 V DC)
○
800 W (–42 V DC to –72 V DC)
○
RG-PA800I-F: Front-to-rear airflow (air exhaust on power
module panel)
RG-PD800I-F: Front-to-rear airflow (air exhaust on power
module panel)
Fan cooling
Swappable fan
0.5 hours
1+1
2+1
Hot swappable power and fan modules
GB/T 9254.1
GB 4943.1
Environment protection regulation
9
