Hardware Installation and Reference Guide
4. Technical Specifications
Table 1-11 Technical Specifications
Class
Physical
characteristics
Ports
Power supply
Reliability
1.4.2

M6500-24VS2CQ

1. Appearance
Figure 1-8 Front Panel Appearance
Table 1-12 Front Panel Components
No. Component
1 Expansion module status LED
2 SFP28 port
3 SFP28 port LED
4 QSFP28 port LED
Item Specification
Dimensions (W x
D x H)
Weight Net weight: 0.97 kg (2.14 lbs.)
16 x 100GE QSFP28 ports, backward compatible with 40GE
Port density
QSFP+, split into four 10GE/25GE ports
Max. power
57 W
consumption
Hot swapping Supported
Without packing materials: 207 mm x 165 mm x 41 mm (8.15
in. x 6.50 in. x 1.61 in.)
With packing materials: 465 mm x 335 mm x 312 mm (18.31
in. x 13.19 in. x 12.28 in.)
12
Overview
