Ports

Table 1-6 Ports
Port
Management port
USB port
Console port
Connector Type
RJ45
USB
RJ45
Description
The management port is used to
set up the onsite or remote
configuration environment.
Standards compliance:
IEEE802.3ab
Working mode: 10/100/1000
Mbps with auto-negotiation
and full-duplex
The USB port is connected with a
USB flash drive for configuration
backup and firmware upgrade.
USB 2.0
FAT32 file format
The console port is connected to a
console for onsite configuration.
Standards compliance: RS-
232
Working mode: Duplex
Universal Asynchronous
Receiver/Transmitter (UART)
Baud rate:
○
Range: 9,600 bit/s to
115,200 bit/s
○ Default value: 9,600 bit/s
5
Overview
Accessory
CAT5 or higher cable
USB 2.0 flash drive
Console cable
