3.1
Installation Procedure
Figure 3-1
Installation Procedure
Start
Prepare
Install the
chassis.
Connect the
grounding wire.
Install the power
module.
Connect the
power cord.
Verify
installation.
Set the power
switch to ON.
Normal?
Yes
Finish
(1)
Installing the Rack
(2)
Installing the Chassis
(3)
Installing the Protective Grounding Wire
(4)
Installing and Removing the Fan Module
(5)
Installing and Removing the Expansion Module
(6)
Insalling and Removing the Power Module
Troubleshoot
No
Set the power
switch to OFF.
36
Installing the Switch
