Hardware Installation and Reference Guide
5
QSFP28 port
Note
The M6500-24VS2CQ has two rows of ports. The ports on the top row start with 1 followed by the
remaining odd-numbered ports, and the ports on the bottom row start with 2 followed by the remaining
even-numbered ports. Ports 25F and 26F are 100GE ports.
The port LEDs are numbered from left to right corresponding to ports 1F to 26F.
2. Ports
Table 1-13
Ports
Port
25GE SFP28
port
100GE
QSFP28 port
3. LEDs
Table 1-14
LEDs
Silkscreen
Label
Status
Connector
Description
Type
The 25GE SFP28 port is backward compatible with
Subject to
10GE for downlink data transmission.
the optical
Working mode: Full-duplex
module
Optical attributes: Subject to the module or
cable
The 100GE QSFP28 port is backward compatible
with 40GE and can be split into four 10GE or 25GE
ports for uplink data transmission.
Working mode: Full-duplex
Subject to
Optical attributes: Subject to the module or
cable
the optical
module
The M6500-24VS2CQ supports 100GE
QSFP28 and 40GE QSFP+ modules, which
are not interchangeable.
LED
Description
Solid green: The expansion module is operating normally.
Blinking green: The expansion module is starting up. Continuous
Expansion
blinking indicates an anomaly.
module status
Solid red: The expansion module is resetting or not functioning
properly.
LED
Solid yellow: The temperature exceeds the limit.
Off: The expansion module is not receiving power.
Note
13
Overview
Accessory
10GE optical module
25GE optical module
AOC
40GE optical module
100GE optical module
AOC
