- Page 1 Ruijie RG-S6520 Series Switches Hardware Installation and Reference Guide Document Version: V1.0 Date: 2022.06.09 Copyright © 2022 Ruijie Networks...
- Page 2 All rights are reserved in this document and this statement. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
- Page 3 Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ...
- Page 4 Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Product Overview
Input Frequency: 50 Hz to 60 Hz Rated current: 5A to 10A Power Less than 600 W Consumption Refer to Appendix B Optical Module The supported modules update at any time, contact Ruijie Networks for details . - 4 -... - Page 6 Hardware Installation and Reference Guide Product Overview SFP28 Port Unsupported QSFP28 Port Supported FC Port Unsupported 10GBASE-T Port Unsupported Temperature Support temperature warning and over-temperature protection. Warning EMC Standards GB9254-1998 FCC CLASS A Safety Standards GB4943-2011 Working 0° C to 45° C (32° F to 113° F) Temperature Storage -40°...
- Page 7 Hardware Installation and Reference Guide Product Overview Notes: Switch status indicator USB 2.0 port Switch locator indicator QSFP28 port Console port QSFP28 port status indicator MGMT port The S6520-64CQ supports 100G QSFP28 module and 40G QSFP+ module. Back Panel Figure 1-3 Back Panel of the S6520-64CQ Notes: Power supply module slot Fan status indicator...
- Page 8 Hardware Installation and Reference Guide Product Overview External Ports The RG-S6520-64CQ provides the following ports: Universal serial bus (USB) port: This port can connect with USB memory to save logs, host versions, warnings and other diagnostic messages. Therefore, it is more convenient to upgrade the software version of the switch on line and save the log information.
- Page 9 Hardware Installation and Reference Guide Product Overview (Front panel/Back One of the modules of the system fails. panel) There are less than 2 fans. Solid red The internal or partial temperature exceeds the warning working temperature, and the switching service resets. Blinking green.
- Page 10 Hardware Installation and Reference Guide Product Overview Leave sufficient space in the front and at the back of the chassis (at least 20 cm) for ventilation. It requires at least two fan modules to work normally. Filler panels need to be installed in the unoccupied fan module slots to ensure ventilation and heat dissipation and avoid dusts.
-
Page 11: Preparation Before Installation
Hardware Installation and Reference Guide Preparation before Installation 2 Preparation before Installation 2.1 Safety Precautions To avoid body injury and device damage, please carefully read the safety precautions before you install the RG - S6520. The following safety precautions do not cover all possible dangers. 2.1.1 Installation Safety ... -
Page 12: Laser Safety
Hardware Installation and Reference Guide Preparation before Installation Any nonstandard and inaccurate electrical operation can cause accidents such as fires or electrical attacks, thus causing severe, or even fatal damages to human bodies and the devices. Direct or indirect touch through a wet object on high-voltage and mains supply can bring a fatal danger. 2.1.4 Electrostatic Discharge Damage Precautions The RG-S6520 designing gives a great consideration to prevent electrostatic discharge damage and adopts multiple measures. -
Page 13: Ventilation Requirements
2.2.2 Ventilation Requirements For the RG-S6520 series products, leave sufficient space in the front and at the back of the chassis (at least 20cm) for ventilation. After various cables are connected, bundle the cables or place them in the cable management bracket to avoid blocking air inlets. -
Page 14: System Grounding Requirements
All the above constitute the comprehensive grounding require ments. The grounding resistance should be less than 1Ω. There is one grounding connector at the right bottom of the chassis of RG-S6520 series switches. The grounding connector is pasted with conspicuous warning labels. -
Page 15: Emi Consideration
Hardware Installation and Reference Guide Preparation before Installation 2.2.6 EMI Consideration Various interference sources, from either outside or inside the device or application system, affect the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interferences: radiated interference and conducted interference, dependi ng on the type of the propagation path. -
Page 16: Unpacking And Checking
Air-laid paper, fiber end microscope Meter Multimeter, errormeter, optic-power meter RG-S6520 series is not shipped with a tool kit. You need to prepare a tool kit by yourself. 2.5 Unpacking and Checking Goods Checklist Chassis, Yellow/green grounding cables; Quick installation guide; Packing list, Pouched... -
Page 17: Product Installation
Product Installation 3 Product Installation RG-S6520 series Ethernet switch must be used and fixed in the room. Make sure you have carefully read part 2, and be sure that the requirements set forth in part 2 have been met. 3.1 Installation Procedure... -
Page 18: Cabinet Installation
Hardware Installation and Reference Guide Product Installation The related network cables have already been deployed at the installation location. 3.3 Cabinet Installation Precautions When you install the cabinet, pay attention to the following requirements: All expansion bolts for fastening the cabinet base to the g round should be installed and tightened in sequence from bottom up (large plain washer, spring washer, and nut), and the installation holes on the base and the expansion bolts should be well aligned. - Page 19 Mounting the Switch to a Rack The RG-S6520 series switches are qualified for EIA standard and can be installed in 19 -inch wiring cabinet. During the process of installation, keep the front panel of the switch forward. It is recommended use tray to install the RG-S6520 series switches and fix the tray on the bracket, or use the rear bracket provided with the switches.
-
Page 20: Installing And Removing A Fan Module
Hardware Installation and Reference Guide Product Installation The mounting brackets are located at the four of the six screw holes at both sides on the back panel of the host. Distinguish the left and the right rear brackets according to the marked directions. The rear brackets provided are only applicable for cabinets with depth of 800mm - 1200mm. - Page 21 Hardware Installation and Reference Guide Product Installation Hold the handle at the end of the fan module. Insert the fan module to the chassis slowly along the guide rail until it is fully seated, and make sure that it is in good contact with the slot. Tighten the captive screws with a screwdriver to fix the fan module in the switch chassis .
- Page 22 Hardware Installation and Reference Guide Product Installation hand. Insert it into the chassis along the guide rail uprightly and slowly until a click is heard, and make sure that it is in good contact with the power slot. Figure 3-5 Installing a power module Insert the power module smoothly.
-
Page 23: Connecting The External Interface Cables
Hardware Installation and Reference Guide Product Installation The cross sectional area of the grounding cable should be determined according to the possible maximum current. Cables of good conductor should be used. Do not use bare wire. The grounding resistance for combined grounding should be less than 1Ω. To guarantee the security of the person and the device, the RG-S6520 must be well-grounded. - Page 24 Hardware Installation and Reference Guide Product Installation When you bind fibers, be sure that the fibers at the connectors have natural bends or bends of large curvature. Do not bind fibers and twisted pairs too tightly, as this may press the fibers and affect their service life and transmission performance.
-
Page 25: System Debugging
Hardware Installation and Reference Guide System Debugging 4 System Debugging 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4 -1. Figure 4-1 Schematic diagram of the configuration environment Connecting the Console Cable Connect one end of the DB-9 jack of the console cable to the serial port of the PC. - Page 26 Hardware Installation and Reference Guide System Debugging Figure 4-2 Enter the name of the new connection and click OK. A window appears as shown in Figure 4-3. In the column of Connect Using field, select the serial port you want to use. Figure 4-3 After the serial port is selected, please click OK.
-
Page 27: Power-On Startup
Hardware Installation and Reference Guide System Debugging After the serial port parameters are set, click OK to enter hyper terminal window. 4.2 Power-on Startup Checking before Power-on Check if the switch is fully grounded. Check if the fan module and the power module are correctly installed. ... -
Page 28: Monitoring And Maintenance
Working status of fan and power supply Temperature status For the monitoring commands, refer to RG-S6520 Series Switch RGOS Configuration Guide. 5.2 Hardware Maintenance Extension Module Maintenance To replace a board, do replacement according to the instructions provided in Sections of Installing Modules and Removing Modules. - Page 29 Replacing Lithium Battery The built-in lithium batteries can support the real time clock of the RG-S6520 series switches without external power supply. Please contact the technical support representatives of Ruijie Networks for replacing lithium batteries. Technical staff of Ruijie Networks will replace the battery of the same model.
-
Page 30: Troubleshooting
Check the indicators on the device and the modules Check the connection of the serial ports and its parameters Check the connection of the fibers or cables of various ports Contact Technical Support of Ruijie Networks for hardware problems - 29 -... -
Page 31: Common Troubleshooting Procedures
RG-S6520 Software Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact Ruijie Customer Service Department for technical support. - Page 32 Check whether the module is inserted correctly. If the newly-inserted module still cannot be powered on even though the checking is ok, please contact Ruijie Customer Service Department for technical support. Fault 7: The link cannot be set up between fiber interfaces [Fault Description] The system runs normally.
-
Page 33: Appendix A Connector And Connection Media
Hardware Installation and Reference Guide Appendix A Connector and Connection Media Appendix A Connector and Connection Media 10GBASE-T/1000BASE-T/100BAS E-TX Port 10GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. 10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed in the following table. - Page 34 Hardware Installation and Reference Guide Appendix A Connector and Connection Media Figure A-1 Four twisted pairs of the 1000BASE-T In addition to the above cables, the 100BASE-TX can use up to 100m of 100-ohm CAT5. Figure A-2 shows the definition of pin signal concerning the 100BASE-TX: Figure A-2 Definition of pin signal concerning the 100BASE-TX Socket...
-
Page 35: Appendix B 10G, 40G And 100G Module
Hardware Installation and Reference Guide Appendix B 10G, 40G and 100G Module Appendix B 10G, 40G and 100G Module We provide 10G SFP+ modules, 40G QSFP+ modules and 100G QSFP28 modules. According to the interface type of the switch module. You can select modules to suit your specific needs. The following models and technical specifications of some 10G SFP+ modules, 40G QSFP+ modules and 100G QSFP28 modules are listed for your reference. - Page 36 Hardware Installation and Reference Guide Appendix B 10G, 40G and 100G Module (MPO 150m (Perlane) 4700 interface) (OM4) 300m 2000 -9.9 to 40G-QSFP- (OM3) -7.6 to 2.3 (MPO LSR-MM850 400m (Perlane) interface) (Perlane) 4700 (OM4) -13.7 to 40G-QSFP- -7.0 to 2.3 1310 10km LR4-SM1310...
-
Page 37: Appendix C Lightning Protection
Hardware Installation and Reference Guide Appendix C Lightning Protection Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row should be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. - Page 38 Hardware Installation and Reference Guide Appendix C Lightning Protection Installing the Ethernet Port Arrester During the switch usage, the Ethernet port arrester should be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch . Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the...
- Page 39 Hardware Installation and Reference Guide Appendix C Lightning Protection You should pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester: Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT”...
-
Page 40: Appendix D Cabling Recommendations In Installation
Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Appendix D Cabling Recommendations in Installation When the switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cable management bracket, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room. - Page 41 Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling and no mixed bundling is allowed. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a distance not less than 30 mm.
- Page 42 Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Figure D-3 Bundling up cables (3) Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or ca use device damage or cable damage during commissioning.
- Page 43 Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Figure D-4 Cable fastening The hard power cable should be fastened at the terminal connection area to prevent stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. ...
-
Page 44: Appendix E Site Selection
Hardware Installation and Reference Guide Appendix E Site Selection Appendix E Site Selection The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
