Hardware Installation and Reference Guide
Table 1-19
Components
No.
Component
1
Handle
2
Fan
3
Power connector
4
LED
5
Latch
2. LED
Table 1-20
LED
Silkscreen
Label
N/A
3. Technical Specifications
Table 1-21
Technical Specifications
Item
Dimensions (W x D x H)
Weight
Power connector
Rated input voltage
Description
Handle of the power module
Forward fan
Three-pin connector
Power status LED
Latch of the power module
LED
Description
Power status
LED
Off: The power module is not receiving power or not operating even
after receiving power.
Specifications
Three-pin connector for connection with the DC power cord
–48 V DC
Solid green: The power module is outputting power normally.
Blinking green at 1 Hz:
The power module is in PS OFF state with only 12 V standby output.
The power module is in the cold standby status and not outputting
power.
Solid red:
The power module is not functioning properly (overcurrent,
overvoltage, or fan failure).
The power module in redundancy mode is removed.
Blinking red at 1 Hz: The power module is operating but with alarms,
such as high power, high current, high temperature, and low fan
rotation speed.
Without packing materials: 73.5 mm x 185 mm x 40 mm (2.89 in. x
7.28 in. x 1.57 in.)
With packing materials: 462 mm x 195 mm x 232 mm (18.19 in. x
7.68 in. x 9.13 in.)
Without packing materials: 0.9 kg (1.98 lbs.)
With packing materials: 1.25 kg (2.76 lbs.)
18
