Hardware Installation and Reference Guide
Figure 3-8 Installing the RG-PA800I-F
Warning

Slide the power module all the way into the chassis gently. Align the power module in the right orientation
to the open power slot.

If you are not able to push the power module all the way into the slot, carefully slide the module out of the
slot, align the module with guide rails, and reinstall the module.

All fan and power modules must have the same airflow direction or else an error can occur.
2. Installing the Power Cord Retainer
(1) Remove the power cord retainer from its packing materials. The power cord retainer consists of a retainer
strip and a retainer clamp.
○ The retainer strip has two sides, one side smooth and the other side grooved.
○
The adjustable retainer clamp has two sides, one side smooth and the other side grooved. The retainer
clamp has two latches. If you want to remove the retainer strip, press the retainer strip latch. If you want
to adjust the retainer clamp, press the clamp latch.
45
Installing the Switch
