Ruijie RG-S6510-48VS8CQ Switch
Hardware Installation and Reference Guide
Document Version: V2.0
Date: August 15, 2023
Copyright © 2023 Ruijie Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-S6510-48VS8CQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-S6510-48VS8CQ

Summary of Contents for Ruijie RG-S6510-48VS8CQ

  • Page 1 Ruijie RG-S6510-48VS8CQ Switch Hardware Installation and Reference Guide Document Version: V2.0 Date: August 15, 2023 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

  • Page 3: Preface

    Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Technical support website: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...
  • Page 4 Specification An alert that contains a description of product or version support. 2. Note The manual offers configuration information (including model, port type and command line interface) for indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the actual version prevails.

  • Page 5: Table Of Contents

    Contents Preface ..............................I 1 Overview ............................1 1.1 About the RG-S6510-48VS8CQ ....................1 1.2 Component Modules ........................1 1.3 Chassis ............................2 1.3.1 Appearance ........................2 1.3.2 LEDs ..........................4 1.3.3 Ports ..........................5 1.3.4 Cooling ........................... 7 1.3.5 Technical Specifications ....................8 1.3.6 Nameplate ........................
  • Page 6 1.6.2 Ethernet Cable ......................34 1.6.3 Power Cord ........................35 1.6.4 Grounding Wire ......................38 1.7 Pluggable Modules ........................39 2 Preparing for Installation ......................... 41 2.1 Safety Guidelines ........................41 2.1.1 General Precautions ....................41 2.1.2 Chassis-Lifting Guidelines ................... 41 2.1.3 Electricity Safety ......................
  • Page 7 2.5 Unpacking the Switch ......................48 2.5.1 Verifying the Shipped Content ..................48 2.5.2 Unpacking the Container ..................... 49 3 Installing the Switch ........................51 3.1 Installation Procedure ......................51 3.2 Installing the Rack........................52 3.2.1 Installation Guidelines ....................52 3.2.2 Procedure ........................
  • Page 8 3.7 Installing the Pluggable Module ....................64 3.8 Verifying Installation ......................... 64 3.9 Connecting the Power Cord..................... 65 4 Commissioning ..........................66 4.1 Setting Up the Configuration Environment ................66 4.2 Powering on the Device ......................68 4.2.1 Checklist Before Power-on ..................68 4.2.2 Power-on ........................
  • Page 9 6.2.4 No Output on the Console ................... 73 6.2.5 Garbled Output on the Console ................... 74 6.2.6 Optical Port Linkdown ....................74 7 Appendix ............................74 7.1 Labeling Process ........................74 7.1.1 Hand Writing on Labels ....................74 7.1.2 Pasting Labels ......................75 7.1.3 Label Contents ......................

  • Page 10: Overview

    Ruijie Networks for data centers and high-end campuses. The RG-S6510-48VS8CQ switch provides high-density 25GE access, 100GE uplink ports, and diverse data center features. It can be used with Ruijie’s RG-N18000- X and RG-S6920-4C switches for a high-performance and high-reliability data center network.

  • Page 11: Chassis

    DC input. For example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted Power Supply (UPS) DC power. Chassis The RG-S6510-48VS8CQ hardware system consists of a chassis, a power supply system, and a cooling system. ...
  • Page 12 Hardware Installation and Reference Guide Overview 2. Structure Figure 1-3 Front Panel Structure Table 1-3 Front Panel Components Component Status LED Locating LED SFP28 port SFP28 port LED QSFP28 port QSFP28 port LED Figure 1-4 Rear Panel Structure Table 1-4 Rear Panel Components Component Power module slot...

  • Page 13: Leds

    Hardware Installation and Reference Guide Overview Component Fan module slot Locating LED Management port USB port Grounding stud Asset tag Status LED Console port 1.3.2 LEDs Table 1-5 LEDs Silkscreen Description Label Solid green: The system is operating normally. Blinking green: The system is starting up. Solid red: ○...

  • Page 14: Ports

    Hardware Installation and Reference Guide Overview Silkscreen Description Label Blinking green: The port is sending and receiving traffic. Off: No link is detected for the port. Solid green: The port has made a successful link. QSFP28 port 49F to 56F Blinking green: The port is sending and receiving traffic.
  • Page 15 Hardware Installation and Reference Guide Overview Port Connector Type Description Accessory The 100GE QSFP28 port is backward compatible with 40GE for uplink data transmission. 40GE optical module Standards compliance: 100GE QSFP28 Subject to the IEEE802.3ba 100GE optical port optical module module Working mode: Full- duplex...

  • Page 16: Cooling

    Hardware Installation and Reference Guide Overview Port Connector Type Description Accessory (UART) Baud rate: ○ Range: 9,600 bit/s to 115,200 bit/s ○ Default value: 9,600 bit/s 1.3.4 Cooling 1. Overview There are two airflow directions available: front-to-rear and rear-to-front.  Front-to-rear: Air flows in through the ports and out through the power module, as shown in Figure 1-5.

  • Page 17: Technical Specifications

    Hardware Installation and Reference Guide Overview Figure 1-6 Rear-to-Front Airflow 1.3.5 Technical Specifications Table 1-7 Technical Specifications Class Item Specification 1.2 GHz quad-core Technical Memory 4 GB, DDR4 (compatible with 8 GB) indicators Flash memory NOR flash: MB (for BootROM)
  • Page 18 Hardware Installation and Reference Guide Overview Class Item Specification NAND flash: 8 GB Without packing materials: 442 mm x 387 mm x 44 Dimensions mm (17.40 in. x 15.24 in. x 1.73 in., 1 RU) (W x D x H) With packing materials: 600 mm x 550 mm x 160 mm (23.62 in.
  • Page 19 Hardware Installation and Reference Guide Overview Class Item Specification Note At an altitude in the range of 2,000–5,000 m (6,561.68–16,404.20 ft.), every time the altitude increases by 200 m (656.17 ft.), the maximum temperature decreases by 1° C (1.8° F). Storage temperature: –40°...
  • Page 20 Hardware Installation and Reference Guide Overview Class Item Specification ○ Max. voltage range: 90 V AC to 264 V AC (47 Hz to 63 Hz) ○ Rated input current: 7.2 A to 3.5 A RG-PA550I-R: ○ Rated voltage: 110 V AC/220 V AC ○...
  • Page 21 Hardware Installation and Reference Guide Overview Class Item Specification power module panel) RG-PHD550I-F: Front-to-rear airflow (air exhaust on power module panel) RG-PD800I-F: Front-to-rear airflow (air exhaust on power module panel) Cooling mode Fan cooling Cooling Fan type Swappable fan Mean Time Between 38.5 years Failure (MTBF)

  • Page 22: Nameplate

    Hardware Installation and Reference Guide Overview the equipment is running. Cut off the power supply before opening the enclosure in case of an electric shock. 1.3.6 Nameplate The nameplate is at the bottom of the chassis, as shown in Figure 1-7.

  • Page 23: Power Modules

    Hardware Installation and Reference Guide Overview Figure 1-8 Asset Tag Power Modules The smart power modules for the RG-S6510-48VS8CQ support power consumption management and hot swapping. They can obtain the output power, output current, and operating temperature in real time. Caution ...

  • Page 24: Rg-Pa550I-F

    Hardware Installation and Reference Guide Overview 1.4.1 RG-PA550I-F 1. Appearance Figure 1-9 Appearance Figure 1-10 Structure Table 1-8 Components Component Description Handle Handle of the power module Forward fan Power Three-pin connector connector...
  • Page 25 Hardware Installation and Reference Guide Overview Power status LED Latch Latch of the power module 2. LED Table 1-9 Silkscreen Description Label Solid green: The power module is outputting power normally. Blinking green at 1 Hz: ○ The power module is in PS OFF state with only 12 V standby output.
  • Page 26 Hardware Installation and Reference Guide Overview Item Specification Without packing materials: 0.9 kg (1.98 lbs.) Weight With packing materials: 1.5 kg (3.31 lbs.) Power connector C14 connector for connection with AC/HVDC power cord Rated input voltage range 100 V AC to 240 V AC, 50 Hz to 60 Hz Max.

  • Page 27: Rg-Pa550I-R

    Hardware Installation and Reference Guide Overview 1.4.2 RG-PA550I-R 1. Appearance Figure 1-11 Appearance Figure 1-12 Structure Table 1-11 Components Component Description Handle Handle of the power module Reverse fan...
  • Page 28 Hardware Installation and Reference Guide Overview Power Three-pin connector connector Power status LED Latch Latch of the power module 2. LED Table 1-12 Silkscreen Description Label Solid green: The power module is outputting power normally. Blinking green at 1 Hz: ○...
  • Page 29 Hardware Installation and Reference Guide Overview Item Specification Weight Without packing materials: 0.9 kg (1.98 lbs.) Power connector C14 connector for connection with AC/HVDC power cord Rated input voltage range 100 V AC to 240 V AC, 50 Hz to 60 Hz Max.

  • Page 30: Rg-Pd800I-F

    Hardware Installation and Reference Guide Overview 1.4.3 RG-PD800I-F 1. Appearance Figure 1-13 Appearance Figure 1-14 Structure Table 1-14 Components Component Description Handle Handle of the power module Forward fan...
  • Page 31 Hardware Installation and Reference Guide Overview Power Three-pin connector connector Power status LED Latch Latch of the power module 2. LED Table 1-15 Silkscreen Description Label Solid green: The power module is outputting power normally. Blinking green at 1 Hz: ○...
  • Page 32 Hardware Installation and Reference Guide Overview Item Specifications With packing materials: 462 mm x 195 mm x 232 mm (18.19 in. x 7.68 in. x 9.13 in.) Without packing materials: 0.9 kg (1.98 lbs.) Weight With packing materials: 1.25 kg (2.76 lbs.) Power connector Three-pin connector for connection with the DC power cord –48 V DC...

  • Page 33: Rg-Phd550I-F

    Hardware Installation and Reference Guide Overview 1.4.4 RG-PHD550I-F 1. Appearance Figure 1-15 Appearance Figure 1-16 Structure...
  • Page 34 Hardware Installation and Reference Guide Overview Table 1-17 Components Component Description Handle Handle of the power module Forward fan Power Three-pin connector connector Power status LED Latch Latch of the power module 2. LED Table 1-18 Silkscreen Description Label Solid green: The power module is outputting power normally.
  • Page 35 Hardware Installation and Reference Guide Overview 3. Technical Specifications Table 1-19 Technical Specifications Item Specification Without packing materials: 73. 5 mm x 185 mm x 40 mm (2.89 in. x 7.28 in. x 1.57 in.) Dimensions (W x D x H) With packing materials: 462 mm x 195 mm x 232 mm (18.19 in.

  • Page 36: Fan Modules

    Hardware Installation and Reference Guide Overview Fan Modules 1.5.1 M6510-FAN-F 1. Appearance Figure 1-17 Appearance Figure 1-18 Structure Table 1-20 Components Component Description Captive screw Captive screw of the fan module...
  • Page 37 Hardware Installation and Reference Guide Overview Handle Handle of the fan module Fan status LED Airflow direction Front-to-rear airflow (air exhaust on fan module panel) notation 2. LED Table 1-21 Silkscreen Description Label Solid green: The fan module is operating normally. Blinking green: The fan module is being initialized.

  • Page 38: M6510-Fan-R

    Hardware Installation and Reference Guide Overview Item Specification Max. airflow volume 31 CFM Max. air pressure 933 Pa Hot swapping Supported Cooling Front-to-rear airflow (air exhaust on fan module panel) Automatic speed regulation Supported Status monitoring Rotation speed monitoring and fault alarm 1.5.2 M6510-FAN-R 1.
  • Page 39 Hardware Installation and Reference Guide Overview Figure 1-20 Structure Table 1-23 Components Component Description Captive screw Captive screw of the fan module Handle Handle of the fan module Fan status LED Airflow direction Rear-to-front airflow (air intake on fan module panel) notation 2.
  • Page 40 Hardware Installation and Reference Guide Overview 3. Technical Specifications Table 1-25 Technical Specifications Item Specification Without packing materials: 46.4 mm x 131.9 mm x 81.2 mm (1.83 in. x 5.19 in. x 3.20 in.) Dimensions (W x D x H) With packing materials: 245 mm x 125 mm x 85 mm (9.65 in.

  • Page 41: M1Efan Iv-R

    Hardware Installation and Reference Guide Overview 1.5.3 M1EFAN IV-R 1. Appearance Figure 1-21 Appearance Figure 1-22 Structure Table 1-26 Components Component Description Captive screw Captive screw of the fan module Handle Handle of the fan module...
  • Page 42 Hardware Installation and Reference Guide Overview Status LED Fan status LED Airflow direction Rear-to-front airflow (air intake on fan module panel) notation 2. LED Table 1-27 Silkscreen Description Label Solid green: The fan module is operating normally. Blinking green: The fan module is being initialized. Fan status Status Solid red: The fan module is not functioning properly.

  • Page 43: Cables

    Hardware Installation and Reference Guide Overview Item Specification Automatic speed regulation Supported Status monitoring Rotation speed monitoring and fault alarm Cables 1.6.1 Console Cable The equipment supports the DB9 to RJ45 console cable consisting of a DB9 female connector on one end and RJ45 male connector on the other. A console cable connects the console port of a switch to the serial port of a terminal, enabling users to configure their equipment locally.

  • Page 44: Power Cord

    Hardware Installation and Reference Guide Overview  10BASE-T: 100-ohm CAT3, CAT4, CAT5, and CAT5e UTP or STP cables with a transmission distance of up to 100 meters (328.08 ft.). Note  For twisted pair connection and pin assignments, see 7.2 Connectors and Media.
  • Page 45 Hardware Installation and Reference Guide Overview 2. AC/HVDC Power Cord Select power cords based on the types of power sockets used in your equipment room. Ruijie provides the following types of power cords to suit different the power sockets: ...
  • Page 46 Hardware Installation and Reference Guide Overview 3. DC Power Cord DC power cords include –48 V power cords and RTN power cords. Choose appropriate DC power cords for different scenarios:  If a switch is connected to a power distribution unit, use DC power cords with an insulated terminal at one end and an OT terminal at the other end.

  • Page 47: Grounding Wire

    Hardware Installation and Reference Guide Overview Figure 1-28 HVDC Power Cord Structure Caution If the switch does not receive power after being connected with the power cord, exchange positive and negative wire connections. 1.6.4 Grounding Wire Table 1-32 Grounding Wire Components Component Description UL1015 16 AWG, yellow-green, 3 meters (9.84 ft.), crimping, rated let-...

  • Page 48: Pluggable Modules

    Hardware Installation and Reference Guide Overview Pluggable Modules Table 1-33 Pluggable Modules Applicable to Chassis 40GE Chassis 1000M Series 10GE Series 25GE Series 100GE Series Series 40G-AOC- 40G-AOC- 40G-AOC- GE-SFP- XG-LR- LH40- SM1310 40G-AOC- SM1310-BIDI XG-SFP- VG-SFP- GE-SFP- AOC1M 40G-AOC- AOC3M LX20- 100G-AOC-...
  • Page 49 Caution  Always use Ruijie certified pluggable modules. Uncertified pluggable modules may lead to service instability. Ruijie will not claim responsibility for the service problems caused by uncertified pluggable modules or provide a solution.  The models of pluggable modules applicable to the chassis are subject to update without prior notification.

  • Page 50: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Guidelines Note  To avoid personal injury or equipment damage, review the safety guidelines in this chapter before you begin the installation.  The following safety precautions may not include all the potentially hazardous situations. 2.1.1 General Precautions ...

  • Page 51: Electricity Safety

    Hardware Installation and Reference Guide Preparing for Installation packing carton during transportation. Avoid placing the chassis side up or upside down.  Do not stack bare demo units. Separate demo units using foam blocks. Do not stack over three layers, each with a height of up to 1 meter (3.28 ft.). Lay the foam blocks side-by-side. 2.1.3 Electricity Safety ...

  • Page 52: Laser Safety

    Hardware Installation and Reference Guide Preparing for Installation 2.1.5 Laser Safety The optical transceivers are Class I laser products. Attention should be paid to the following items:  When an optical transceiver is working, ensure that the port is connected to an optical cable or covered by a dust cap to keep out dust and prevent burning your eyes.

  • Page 53: Temperature

    Hardware Installation and Reference Guide Preparing for Installation easily.  The front and rear of the chassis must remain unobstructed to ensure adequate airflow and prevent overheating inside the chassis. 2.2.4 Temperature To ensure normal operation and prolonged service life of the equipment, maintain an appropriate temperature in the equipment room.

  • Page 54: System Grounding

    Hardware Installation and Reference Guide Preparing for Installation Table 2-1 Dust and Particles Requirement Minimum Dust and Unit Maximum Quantity Particles Diameter 0.5 μm 3.5 x 10 Particles/m 5 μm Particles/m 3.0 x 10 Apart from dust, there are also requirements on the salt, acid, and sulfide in the air of the equipment room.

  • Page 55: Preventing Electromagnetic Interference

    Hardware Installation and Reference Guide Preparing for Installation Ensure that the rack and power distribution system are securely grounded. Otherwise, electric shocks may occur when the insulation resistance between the power module and the chassis becomes small. Caution The building should provide a protective ground connection to ensure that the equipment is connected to a protective earth.

  • Page 56: Surge Protection

    Hardware Installation and Reference Guide Preparing for Installation  Keep the equipment far away from the grounding facility and surge protector facility of the power device.  Keep the equipment far away from high-frequency current devices such as the high-power radio transmitting station and radar launcher.

  • Page 57: Tools

    Hardware Installation and Reference Guide Preparing for Installation mm (6.10 in.). The rack depth (distance between front and rear doors) is at least 1,000 mm (39.37 in.). (4) The guide rails or tray can bear the weight of the chassis and its components. (5) The rack has a reliable grounding terminal for the chassis to connect to earth ground.

  • Page 58: Unpacking The Container

    Hardware Installation and Reference Guide Preparing for Installation Note The preceding items are delivered against the purchase contact. Check your goods carefully against Package Contents or purchase contract. If you have any questions, contact your distributor. 2.5.2 Unpacking the Container Cut off the packing straps on the shipping box with scissors, place the box on a flat surface, and check whether the seal on top of box is intact.
  • Page 59 Hardware Installation and Reference Guide Preparing for Installation Figure 2-5 Figure 2-6 Place the switch with the panel foam facing upwards. Remove the panel foam and set it aside. Move the switch with both hands onto the shipping box of another product, and remove the foam on the other side.

  • Page 60: Installing The Switch

    Hardware Installation and Reference Guide Installing the Switch Installing the Switch Make sure that guidelines and requirements in chapter 2 have been met before you begin the installation. Plan for the installation site, networking mode, power supply, and cabling in advance.

  • Page 61: Installing The Rack

    Hardware Installation and Reference Guide Installing the Switch Installing the Rack Installing the Chassis Installing the Protective Grounding Wire Installing and Removing the Fan Module Installing and Removing the Power Module Installing the Pluggable Module Verifying Installation Connecting the Power Cord Installing the Rack 3.2.1 Installation Guidelines...

  • Page 62: Procedure

    Hardware Installation and Reference Guide Installing the Switch Note Site Selection  for site selection guidelines.  7.5 Recommended Cabling for cabling guidelines. 3.2.2 Procedure (1) Make sure that there is enough space before installing the rack. Reserve enough clearance before the front and rear doors for equipment maintenance.

  • Page 63: Mounting The Chassis On The Rack

    Hardware Installation and Reference Guide Installing the Switch Figure 3-2 Installing the Brackets 3.3.3 Mounting the Chassis on the Rack The chassis can be installed on a standard 19-inch EIA rack. Mount the chassis on the rack with its front panel facing forward. You are advised to use a tray or guide rails to assist in installing the chassis on the rack.

  • Page 64: Mounting The Chassis On The Workbench

    Hardware Installation and Reference Guide Installing the Switch Caution  Install the L-bracket by driving screws into the four among six screw holes on each side.  Distinguish left and right rack-mount guide rails according to the notations.  The rack-mount guide rails delivered with the chassis are applicable to a cabinet with a depth ranging from 800 mm (31.50 in.) to 1,200 mm (47.24 in.).

  • Page 65: Installing And Removing The Fan Module

    Hardware Installation and Reference Guide Installing the Switch (2) Crimp one end of the grounding wire to the grounding terminal of the chassis and the other end to the grounding terminal of the rack or the grounding bar of the equipment room. Danger ...

  • Page 66: Removing The Fan Module

    Hardware Installation and Reference Guide Installing the Switch Warning  Slide the fan module all the way into the chassis gently. Align the fan module in the right orientation to the open fan slot.  If you are not able to push the fan module all the way into the slot, carefully slide the module out of the slot and repeat step 2 to reinstall the module.

  • Page 67: Installing The Rg-Pa550I-F Or Rg-Pa550I-R

    Hardware Installation and Reference Guide Installing the Switch 3.6.1 Installing the RG-PA550I-F or RG-PA550I-R 1. Installing the Power Module (1) Remove the power module from its packing materials. Make sure the input indicators meet the requirements. (2) Remove the filler panel from the slot by unscrewing the captive screw. Keep the panel with the nameplate facing upwards.
  • Page 68 Hardware Installation and Reference Guide Installing the Switch Figure 3-8 Retainer Strip, Retainer Clamp, and Latches (2) Thread the retainer strip through the hole at the bottom of the clamp and lock it into place, as shown in Figure 3-9. If you want to remove the strip, press the retainer strip latch and pull the strip out.

  • Page 69: Installing The Rg-Phd550I-F

    Hardware Installation and Reference Guide Installing the Switch Figure 3-10 Retainer Clamp 3.6.2 Installing the RG-PHD550I-F (1) Remove the power module from its packing materials. Make sure the input indicators meet the requirements. (2) Remove the filler panel from the slot by unscrewing the captive screw. Keep the panel with the nameplate facing upwards.
  • Page 70 Hardware Installation and Reference Guide Installing the Switch Figure 3-11 Installing the RG-PHD550I-F (4) Slide the retainer clamp around the power cord. Press the latch to adjust the retainer clamp for securing the power cord. Figure 3-12 Installing the Power Cord Retainer Warning ...

  • Page 71: Installing The Rg-Pd800I-F

    Hardware Installation and Reference Guide Installing the Switch 3.6.3 Installing the RG-PD800I-F (1) Remove the power module from its packing materials. Make sure the input indicators meet the requirements. (2) Remove the filler panel from the slot by unscrewing the captive screw. Keep the panel with the nameplate facing upwards.

  • Page 72: Removing The Power Module

    Hardware Installation and Reference Guide Installing the Switch Figure 3-15 Installing the RG-PD800I-F Warning  Slide the power module all the way into the chassis gently. Align the power module in the right orientation to the open power slot.  If you are not able to push the power module all the way into the slot, carefully slide the module out of the slot, align the module with guide rails, and reinstall the module.

  • Page 73: Installing The Pluggable Module

    Make sure that you have mounted the chassis on the rack before installing the pluggable module.  For procedure, see Ruijie Optical Module Hardware Installation and Reference Guide for details. The documentation is subject to update without prior notification. Please access Ruijie Networks at https://www.ruijienetworks.com/...

  • Page 74: Connecting The Power Cord

    Hardware Installation and Reference Guide Installing the Switch  The chassis has been mounted on the rack and all cables have been fastened to the rack.  Select the proper fan module and tighten captive screws.  Select the proper power module. ...

  • Page 75: Commissioning

    Hardware Installation and Reference Guide Commissioning Commissioning Setting Up the Configuration Environment Connect the serial port of a PC to the console port of the device with a cable, as shown in Figure 4-1. Figure 4-1 Configuration Environment Device Console port Serial port Console cable The first login to the device must be performed through the console port.
  • Page 76 Hardware Installation and Reference Guide Commissioning b Click Serial in the left column. Set Bits per second to 115,200, Data bits to 8, Parity to None, Stop bits to 1, and Flow control to None. Click Open to set up the connection.

  • Page 77: Powering On The Device

    Hardware Installation and Reference Guide Commissioning (4) After setting up the configuration environment, power on the device. If the device is already configured with a password, a notification will appear. Click Accept, and enter your username and password for connection. Powering on the Device 4.2.1 Checklist Before Power-on...

  • Page 78: Monitoring And Maintenance

    Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring 5.1.1 Monitoring the LEDs Each module installed in the chassis features a LED, which can be used to monitor the status of each module while the switch is running. See 1 Overview for details.

  • Page 79: Maintenance

    Hardware Installation and Reference Guide Monitoring and Maintenance  You can log in to the device through Telnet or SSH for maintenance by running CLI commands. Maintenance 5.2.1 Replacing the Power Module The power failure will be prompted through monitoring signals. In the case of a power failure, contact your distributor or technical support team.

  • Page 80: Replacing The Fuse

    5.2.4 Replacing the Fuse To replace the fuse, please contact your distributor or technical support team. Table 5-2 Fuse Specifications Chassis Fuse Bits Specifications RG-S6510-48VS8CQ 5 A/125 V...

  • Page 81: Troubleshooting

    Hardware Installation and Reference Guide Troubleshooting Troubleshooting Flowchart The equipment is not working properly. Check whether the rack is installed properly. Check whether the chassis is mounted on the rack properly. Check whether the power cord is connected properly. Check whether the power module is installed properly.

  • Page 82: Common Issues

    Hardware Installation and Reference Guide Troubleshooting Common Issues 6.2.1 Forgetting Login Password Symptom The login password is forgotten. Handling Method Contact technical support team. 6.2.2 AC Power Module Failure Symptom All LEDs on the front panel are off. The fan status LED is off, and the fan does not rotate. Handling Method Unplug the power cord from the power module.

  • Page 83: Garbled Output On The Console

    Hardware Installation and Reference Guide Appendix 6.2.5 Garbled Output on the Console Symptom The console output is garbled. Handling Method The fault is related to the serial port configuration. Check whether baud rate configuration is consistent with that in Configuration Guide. 6.2.6 Optical Port Linkdown Symptom...

  • Page 84: Pasting Labels

    Hardware Installation and Reference Guide Appendix 7.1.2 Pasting Labels Fill in the label content on the full-page label paper before attaching the label, and then paste it on the power cord or signboard wire buckle. (1) Label pasting position Paste the label 2 cm (0.79 in.) away from the plug. In some specific situations, avoid cable bending or the position that affects power cord installation.

  • Page 85: Label Contents

    Hardware Installation and Reference Guide Appendix Figure 7-2 Signal Cable Labeling Procedure 7.1.3 Label Contents The contents of the two sides of the label identify the location of the ports connected to the two ends of the power cord. Fill in the label according to the specific environment. (1) Fill the content of the local end of the cord location in area ①.
  • Page 86 Hardware Installation and Reference Guide Appendix twisted pair connection for the 1000BASE-T port. The connection method and signal description are provided considering self-made cables. Keep the side without the RJ45 locking clip facing yourself. The signal cables are numbered 1 to 8 from left to right. Figure 7-4 Cable Connection Modes and Signals Table 7-1...

  • Page 87: 100Base-Tx/10Base-T Port

    Hardware Installation and Reference Guide Appendix Figure 7-5 1000BASE-T Twisted Pair Connections 7.2.2 100BASE-TX/10BASE-T Port Table 7-2 100BASE-TX/10BASE-T Pin Assignment MDI Mode MDI-X Mode Output Transmit Data+ Input Receive Data+ Output Transmit Data– Input Receive Data-– Input Receive Data+ Output Transmit Data+ Input Receive Data–...

  • Page 88: Surge Protection

    Hardware Installation and Reference Guide Appendix Figure 7-6 100BASE-TX/10BASE-T Twisted Pairs Surge Protection 7.3.1 Installing an AC Power Arrester When an AC power cord from outdoors is directly plugged into the power port of the switch, the AC power connector must be connected to an external surge protector power strip to protect the switch against lightning strikes.

  • Page 89: Installing An Ethernet Port Arrester

    Hardware Installation and Reference Guide Appendix Note The power arrester does not come with the equipment. Please purchase it based on actual requirements. Important points:  Make sure that the PE terminal of the power arrester is well grounded.  After the AC power plug of the switch is connected to the socket of the power arrester (surge protector power strip), the surge protection function is implemented only if the LED indicating operation status is green and the LED indicating alarm status is OFF.

  • Page 90: Site Selection

    Hardware Installation and Reference Guide Appendix Figure 7-8 Installing an Ethernet Port Arrester Note  The Ethernet port arrester is only for the 10/100 Mbps electrical ports with an RJ-45 connector.  The Ethernet port arrester is not delivered with the switch. Please purchase it as required. The Ethernet port arrester user manual contains technical parameters and maintenance and installation instructions for the Ethernet port arrester.

  • Page 91: Recommended Cabling

    Hardware Installation and Reference Guide Appendix temperature control. Saline soil cannot be used for construction. Otherwise, you should select equipment with advanced protection against severe environment.  Do not build the equipment room in the proximity of livestock farms. Otherwise, the equipment room should be located on the windward side of the pollution source perennially.
  • Page 92 Hardware Installation and Reference Guide Appendix diameters. ○ The bend radius of a fixed common coaxial cable should be over seven times greater than its diameter. The bend radius of the common coaxial cable that is often bent or plugged should be over 10 times greater than its diameter. ○...
  • Page 93 Hardware Installation and Reference Guide Appendix  Use cable ties to bundle up cables properly. Please do not connect two or more cable ties to bundle up cables.  After bundling up cables with cable ties, cut off the remaining part. The cut should be smooth and trim, without sharp corners, as shown in Figure 7-10.
  • Page 94 Hardware Installation and Reference Guide Appendix  For the cable terminals fastened by screw threads, tighten the bolt or screw and take cable retention measures, as shown in Figure 7-12. Figure 7-12 Cable Fastening  Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable.
