Hardware Installation and Reference Guide
2. AC/HVDC Power Cord
Select power cords based on the types of power sockets used in your equipment room. Ruijie provides the
following types of power cords to suit different the power sockets:

Power distribution unit (PDU) cords: C13 straight female to C14 straight male AC power cords, delivered with
a PDU with C14 straight female connectors, as shown in Figure 1-17.

Country-specific power cords: delivered in compliance with standards of the destination country or region.
For example, AC power cords with PI angle male connectors are used in China, as shown in
Figure 1-16 IEC Standard Power Cord Structure
Figure 1-17 GB Standard Power Cord Structure
3. DC Power Cord
DC power cords include –48 V power cords and RTN power cords. Choose appropriate DC power cords for
different scenarios:

If a switch is connected to a power distribution unit, use DC power cords with an insulated terminal at one
end and an OT terminal at the other end.

If a switch is directly connected to a power distribution cabinet, use DC power cords with an insulated terminal
at one end and determine the cable length and terminal type at the other end based on the site survey result.
23
Overview
Figure 1-17.
