Ruijie RG-S6510-48VS8CQ Hardware Installation And Reference Manual
Hide thumbs
Also See for RG-S6510-48VS8CQ:
- Installation and reference manual (49 pages) ,
- Hardware installation and reference manual (94 pages) ,
- Hardware installation and reference manual (82 pages)
Related Manuals for Ruijie RG-S6510-48VS8CQ
Summary of Contents for Ruijie RG-S6510-48VS8CQ
- Page 1 Ruijie RG-S6510-48VS8CQ Switch Hardware Installation and Reference Guide Document Version: V1.0 Date: 2022.06.09 Copyright © 2022 Ruijie Networks...
- Page 2 All rights are reserved in this document and this statement. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
- Page 3 Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ...
- Page 4 Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Product Overview
RG-S6510-48VS8CQ is a high density 10GE/25GE data center access switch, featuring 25GE/100GE access, low latency, and complete data center features . The RG-S6510-48VS8CQ switch, with up to 48 25GE ports and eight 100GE ports, can be used with the RG-N18000-X/RG-S6500-4C switch to compose a high-performance and high-reliability data center network. - Page 6 442 mm x 387 mm x 44 mm (17.40 in. x 15.24 in. x 1.73 in.), 1 RU (W x D x H) RG-S6510-48VS8CQ switch is a class A product. Operation of this equipment in a residential environment could cause radio interference, in which case the user may be required to take adequate measures.
- Page 7 Hardware Installation and Reference Guide Product Overview Front Panel Figure 1-2 Front Panel System Status LED SFP28 Port LED Locator LED QSFP28 Port SFP28 Port QSFP28 Port LED The S6510-48VS8CQ switch supports the 100GE QSFP28 module and 25GE SFP28 module. Back Panel Figure 1-3 Back Panel Power Module Slot...
- Page 8 To protect data and avoid equipment damage, use a qualified USB flash drive. The USB port is compatible with most USB flash drives and may fail to identify some brands. The RG-S6510-48VS8CQ switch supports commissioning, configuration, maintenance, management and program uploading through the console port.
- Page 9 At least one power module is required. If any slot is unoccupied, install a filler panel to enable proper airflow. Heat Dissipation The working temperature of the RG-S6510-48VS8CQ switch ranges from 0° C to 45° C (32° F to 113° F). The heat dissipation design needs to ensure equipment stability, safety and maintainability in such an environment. The RG- S6510-48VS8CQ switch adopts fan ventilation and enforced convection to ensure the equipment can work normally in the specified environment.
- Page 10 Hardware Installation and Reference Guide Product Overview Maintain a minimum clearance of 20 cm (7.87 in.) around the chassis for ventilation. At least three fan modules are required. If any slot is unoccupied, install a filler panel to enable proper airflow and avoid dust.
-
Page 11: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation 2 Preparing for Installation 2.1 Safety Precautions To avoid personal injury and equipment damage, carefully read the safety precautions before you install the switch. The following safety precautions may not cover all possible dangers. 2.1.1 Installation ... -
Page 12: Installation Environment Requirements
Hardware Installation and Reference Guide Preparing for Installation Make sure that the equipment is powered off when you cut off the power supply. Do not place the switch in a wet position, and keep the switch away from li quid. Any nonstandard and inaccurate operation can cause an accident such as fire or electrical attack, thus causing severe damages to human bodies and equipment. -
Page 13: Temperature And Humidity
Model Working Temperature Working Humidity RG-S6510-48VS8CQ 0º C to 45º C (32º F to 113º F) 10% to 90% (non-condensing) The ambient temperature and humidity of the switch are measured at the point that is 1.5 m (59.06 in.) above the floor and 0.4 m (15.75 in.) before the rack when there is no protective plate in the front or at the back of the rack. - Page 14 Hardware Installation and Reference Guide Preparing for Installation The Average refers to the average limit of harmful gas in one week. The Maximum value is the upper limit of the harmful gas measured in one week for up to 30 minutes every day. 2.2.5 Grounding A proper grounding system is the basis for stable and reliable running and is indispensable for preventing lightning strikes and interference.
-
Page 15: Fiber Connections
Hardware Installation and Reference Guide Preparing for Installation All interference sources, either from outside or inside of the equipment or application system, affect the equipment by capacitive coupling, inductive coupling, or electromagnetic waves. Electromagnetic interference (EMI) occurs due to electromagnetic radiation or conduction, depending o n the transmission path. - Page 16 Hardware Installation and Reference Guide Preparing for Installation Unpacking the Carton 1. Cut off the packing tape of the shipping container with scissors, place it on a flat surface with the shipping container facing upward, and check whether the seal on its top surface is intact. 2.
-
Page 17: Installing The Switch
Hardware Installation and Reference Guide Installing the Switch 3 Installing the Switch The switch must be installed indoors. Make sure that requirements in Chapter 2 are all met. 3.1 Installation Procedure - 16 -... -
Page 18: Before You Begin
Hardware Installation and Reference Guide Installing the Switch Prepare for installation Prepare for installation Install the rack Mount the switch into the rack Ground the switch Turn on the power Install the modules Connect the cables Bundle the cables Verify the installation 3.2 Before You Begin Confirm the following before installation: - 17 -... -
Page 19: Mounting The Cabinet
Hardware Installation and Reference Guide Installing the Switch The installation site provides sufficient space for heat dissipation. The installation site meets the temperature and humidity requirements of the switch. The power supply and required current are available in the installation site. ... -
Page 20: Mounting The Brackets
Hardware Installation and Reference Guide Installing the Switch Before installing the switch in a cabinet, please check whether the racks are properly positioned. If the racks are too close to the front door of the cabinet, you may not be able to close the front door after plugging in the Ethernet and fiber cables . The front panel of the switch should be at least 10 mm (0.39 in.) away from the front door of the cabinet. -
Page 21: Mounting The Switch On A Workbench
Hardware Installation and Reference Guide Installing the Switch Install a mounting bracket by driving four screws into the four among the six screw holes on each side of the panel. Distinguish left and right rack-mount guides according to the marked orientation. The rack-mount guides are only applicable for a rack with a depth ranging from 800 mm (31.50 in.) to 1200 mm (47.24 in.). -
Page 22: Installing And Removing A Fan Module
Hardware Installation and Reference Guide Installing the Switch 3.5 Installing and Removing a Fan Module Wear an anti-static wrist strap before the following operations. Installing a Fan Module Take a fan module from its packing materials. Grasp the handle and slide the module into the slot along the guide rail until you feel the connector snap into place. Tighten the captive screws to secure the fan module in the chassis. - Page 23 Hardware Installation and Reference Guide Installing the Switch Slide the fan module into the slot. Verify that the fan module is in the correct orientation. If you find it difficult to fully insert the fan module, pull the fan module out, and slide it into the slot again. If you cannot fully tighten the captive screws , it indicates that the fan module is not fully inserted into the fan slot.
- Page 24 Hardware Installation and Reference Guide Installing the Switch Slide the power module into the slot gently. Verify that the power module is in the correct orientation. If you find it difficult to fully insert the power module, pull the power module out, align it to the guide rails and slide it into the slot again.
- Page 25 Hardware Installation and Reference Guide Installing the Switch Check whether the retainer strip is seated securely. If you can remove the strip without pressing the retainer strip latch, it indicates that the strip is not installed properly. Try the other side of the strip. Fix the strip in the power cord retainer to the power module, to hold the clamp in place.
- Page 26 Hardware Installation and Reference Guide Installing the Switch Pull the power module out of the slot gently. Install the filler panel in the empty slot to allow for adequate airflow and keep out dust. 3.6.2 Installing the RG-PHD550I-F Module Installing a Power Module Remove the power module from its packing materials and make sure the input specifications meet requirements.
- Page 27 Hardware Installation and Reference Guide Installing the Switch Slide the power module into the slot gently. Verify that the power module is in the correct orientation. If you find it difficult to fully insert the power module, pull the power module out, align it to the guide rails and slide it into the slot again.
- Page 28 Hardware Installation and Reference Guide Installing the Switch 3.6.3 Installing the RG-PD800I-F Module Installing a Power Module Remove the power module from its packing materials and make sure the input specifications meet requirements. Remove the filler panel covering the slot. Keep the module nameplate face upward. Grasp the handle with one hand and place your other hand under the power module to support its weight.
- Page 29 Hardware Installation and Reference Guide Installing the Switch Slide the power module into the slot gently. Verify that the power module is in the correct orientation. If you find it difficult to fully insert the power module, pull the power module out, align it to the guide rails and slide it into the slot again.
-
Page 30: Connecting The Console Port
Hardware Installation and Reference Guide Installing the Switch Connect the PGND to the grounding lug of the rack and then connect the grounding lug to the grounding bar of the equipment room. Precautions The sectional area of the grounding wire should be determined according to the possible maximum current. Cables of good conductor should be used. -
Page 31: Bundling Cables
Hardware Installation and Reference Guide Installing the Switch 3.10 Bundling Cables Precautions The power cords and other cables should be bound in a visually pleasing way. When you bind fibers, be sure that the fibers at the connectors have natural bends or bends of large radius. ... -
Page 32: System Commissioning
Hardware Installation and Reference Guide System Commissioning 4 System Commissioning 4.1 Setting Up the Configuration Environment Setting Up the Configuration Environment Connect the PC to the console port of the switch through the Ethernet cable. Figure 4-1 Configuration Environment Connecting the Ethernet Cable ... - Page 33 Hardware Installation and Reference Guide System Commissioning In the Name box, enter the new connection name and click OK. The Connect to dialog will appear. From the Connect using drop-down list, select a COM port.错误!未找到引用源。Figure 4-3 Click OK. The COM1 Properties dialog box will appear. Select the following settings: Bits per second: 9600; Data bits: 8;...
-
Page 34: Powering On The Switch
Hardware Installation and Reference Guide System Commissioning Click OK and the HyperTerminal window will appear. 4.2 Powering On the Switch Checklist before Power-On The switch is fully grounded. The fan module and the power module are properly installed. ... -
Page 35: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance 5 Monitoring and Maintenance 5.1 Monitoring Indicator When the switch is running, you can monitor the module status by observing the LED. If the Status LED is red, it indicates that the system is not functioning properly. Log in to the software management system to troubleshoot the fault. - Page 36 Hardware Installation and Reference Guide Monitoring and Maintenance To replace fuses, contact technical support. - 35 -...
-
Page 37: Troubleshooting Flowchart
Check the installation of other modules Check the LEDs on the device Check serial port connection and parameters Check the cable connection Contact Technical Support of Ruijie Networks 6.2 Common Troubleshooting Procedures Fault 1: The login password is forgotten. Fault Symptom The login password is forgotten. - Page 38 Hardware Installation and Reference Guide Troubleshooting Handling Method Contact technical support. Fault 2: The AC power module does not work. Fault Symptom All LEDs on the front panel are off. The fan status LED is off, and the fan does not rotate. The power supply status LED is off.
- Page 39 Hardware Installation and Reference Guide Troubleshooting Fault Symptom The system runs normally. After you insert an optical transceiver into an optical port and plug in a fiber cable, the link cannot be set up. Handling Method Check whether the receive and transmit ends are reversed. The transm it end of a fiber port must be connected to the receive end at the other end.
- Page 40 Hardware Installation and Reference Guide Appendix 7 Appendix 7.1 Connectors and Media 10GBASE-T/1000BASE-T/100BAS E-TX Port The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. The 10GBASE-T port complies with the IEEE 802.3an standard, and uses four pairs of connected wires for transmission. The following table shows the connection of the twisted pairs used by the 10GBASE -T port.
- Page 41 Hardware Installation and Reference Guide Appendix The 1000BASE-T port complies with the IEEE 802.3ab standard, and uses 100-ohm CAT5, CAT5E or cables with a higher standard for transmission over a distance reach of up to 100 meters . The 1000BASE-T port requires four pairs of connected wires for transmission.
- Page 42 Hardware Installation and Reference Guide Appendix - 41 -...
- Page 43 Hardware Installation and Reference Guide Appendix 7.2 10GE, 25GE, 40GE, and 100GE Modules We provide 10GE SFP+ modules, 40GE QSFP+ modules, and 100GE QSFP28 modules, and AOC cables according to the port types. You can select modules to suit your specific needs. The following models and technical specifications are listed for your reference.
- Page 44 Hardware Installation and Reference Guide Appendix 100m SFP28-SR (840, 860) 50/125 4700 -8.4 -10.3 connector) (OM4) (1295, SFP28-LR 9/125 10km -4.5 -11.4 1325) connector) Existing 25GE SFP28 AOC cables: Copper Module Connector Conductor Wire Support Model Cable Data Rate(Gb/s ) Type Type Diameter (AWG)
- Page 45 Ensure that the port is covered with a dust cap to keep out dust if it is not connected with a fiber cable. The S6510-48VS8CQ switch requires optical transceivers certified by Ruijie networks . The optical transceivers mentioned in this guide are certified by Ruijie Networks. If you want to latest information about certified optical transceivers, contact Ruijie Networks .
-
Page 46: Surge Protection
Hardware Installation and Reference Guide Appendix 7.3 Surge Protection Installing AC Power Arrester (Surge Protection Power Strip) The AC power port must be connected to an external surge protection power strip to prevent the switch from being struck by lightning when the AC power cord is introduced from the outdoor and directly connected to the power port of the switch. - Page 47 Hardware Installation and Reference Guide Appendix Installing the Ethernet Port Arrester Please connect an Ethernet port arrester to the switch to prevent the damage by lightning before connecting an outdoor Ethernet cable to the switch. Tools: Phillips screwdrivers or flat-head screwdriver, multimeter, and diagonal pliers Installation Steps: Tear one side of the protective paper for the double-sided adhesive tape and paste the tape to the housing of the Ethernet port arrester.
- Page 48 Hardware Installation and Reference Guide Appendix Reversed installation direction of the arrester. Connect the external Ethernet cable to the IN end and connect the Ethernet port of the switch to the OUT end. Poor grounding of the arrester. The ground cable of the arrester should be as short as possible to ensure that it is in good contact with the ground terminal of the switch.
-
Page 49: Cabling Recommendations
Hardware Installation and Reference Guide Appendix 7.4 Cabling Recommendations When the switch is installed in a standard 19-inch rack, secure the cables around the cable management brackets. Top cabling or bottom cabling is adopted according to the actual situation in the equipment room. All transferred cable connectors should be placed at the bottom of the rack in an orderly manner instead of outside the rack that is easy to touch. - Page 50 Hardware Installation and Reference Guide Appendix Cables of different types (such as power cords, signal cables, and ground cables) should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, it is recommended to adopt crossover cabling.
- Page 51 Hardware Installation and Reference Guide Appendix Figure 7-9 Bundling Up Cables (3) Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the rack or cable trough. The proper position refers to a position that does not affect switch performance or damage the switch or cable.
- Page 52 Hardware Installation and Reference Guide Appendix Figure 7-10 Cable Fastening Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. Power cords of the same type and in the same cabling direction should be bundled up into cable bunches, with cables in cable bunches clean and straight.
-
Page 53: Site Selection
Hardware Installation and Reference Guide Appendix 7.5 Site Selection The equipment room should be at least 5 km away from heavy pollution sources, such as the smelter works, coal mine, and thermal power plant. The equipment room should be at least 3.7 km away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
