Hardware Installation and Reference Guide
Class
Environment
Power supply
Item
Management port
Altitude
Temperature
Humidity
Noise
Surge protection
Power supply
mode
Power connector
Power consumption
Voltage
AC input
Specification
1 x Gigabit RJ45 port supporting backward compatibility
Operating altitude: 0–5,000 m (16,404.20 ft.)
Storage altitude: 0–5,000 m (16,404.20 ft.)
Operating temperature: 0° C to 40° C (32° F to 104° F) at an
altitude in the range of 0–2,000 m (0–6,561.68 ft.)
Note
At an altitude in the range of 2,000–5,000 m
(6,561.68–16,404.20 ft.), every time the altitude
increases by 200 m (656.17 ft.), the maximum
temperature decreases by 1° C (1.8° F).
Storage temperature: –40° C to +70° C (–40° F to
+158° F)
Operating humidly: 10% RH to 90% RH (non-
condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
Sound pressure level at 27° C(80.6° F): < 78 dB
AC power protection
Common mode: 2 kV
Differential mode: 1 kV
AC
DC
High-voltage DC (HVDC)
Three-pin connector, subject to the power module
Max: 650 W
Typical: 455 W
Static: 202 W
AC: 100 V AC to 240 V AC, 50 Hz to 60 Hz
DC: –36 V DC to –72 V DC
HVDC: 180 V DC to 310 V DC
RG-PA800I-F:
Rated voltage: 110 V AC/220 V AC
Rated voltage range: 100 V AC to 120 V AC/ 200 V AC to
240 V AC (50 Hz to 60 Hz)
Max. voltage range: 90 V AC to 264 V AC (47 Hz to 63
Hz)
Max. current: 10 A to 5 A
8
