Hardware Installation and Reference Guide
(7) Installing and Removing the Pluggable Module
(8) Verifying Installation
(9) Connecting the Power Cord
3.2

Installing the Rack

3.2.1

Installation Guidelines

Make sure the following guidelines are met:

All expansion bolts for securing the rack base to the ground are installed from bottom to up in the sequence
of large flat washer, spring washer, and nut, and the installation holes on the base are flush with the expansion
bolts.

The rack is stable and sturdy after installation has been completed.

The rack is installed on the ground vertically.

When multiple racks are placed side by side in the equipment room, they are parallel in a line with a deviation
of up to 5 mm (0.20 in.).

The front and rear doors of the rack can open and close properly after installation has been completed. Also
verify that the cabinet locks are functioning and that there are a complete set of keys.

All labeling on the rack and equipment is accurate.

Filler panels are installed in the empty slots.

All the screws and bolts that will be used to install the rack are of the same type.

All modules installed in the equipment are secured and all captive screws are properly tightened.

In order to prevent rodents and other small animals from entering the rack, the cabling exit openings at the
top and bottom of the rack are fitted with rodent-resistant nets with seams of up to 15 mm (0.59 in.) in diameter.

The rack always has a set of static-preventive wrist straps available.
Note

See 7.4

See 7.5 Recommended Cabling
3.2.2

Procedure

(1) Make sure that there is enough space before installing the rack. Reserve enough clearance before the front
and rear doors for equipment maintenance.
(2) Mount and fasten the rack in the planned location.
(3) Install the appropriate chute and cables.
(4) Fit the appropriate accessories to the rack.
Site Selection for site selection guidelines.
for cabling guidelines.
37
Installing the Switch
