Hardware Installation and Reference Guide
1

Overview

1.1

About the RG-S6510-4C

The RG-S6510-4C switch is a next-generation switch featuring high-performance, high-density, and low-latency
launched by Ruijie Networks for data centers and high-end campuses. The RG-S6510-4C switch provides a
flexible modular design, 100GE uplink ports, and diverse data center features. It can be used with Ruijie's RG-
N18000-X and RG-S6920-4C switches for a high-performance and high-reliability data center network.
Table 1-1 RG-S6510-4C Overview
Chassis
RG-S6510-4C
M6500-08CQ
M6500-24VS2CQ
Note
The product images involved in this manual are for indicative purpose only. The appearance is subject to the
actual equipment.
1.2

Component Modules

The RG-S6510-4C adopts the modular design. Compliant with industry standards, the design differentiates
modules and integrates module interfaces to ensure an integrated system with independent function modules.
Table 1-2 Component Modules
Chassis
RG-S6510-4C
Caution

Different power modules are interchangeable. That is, the switch allows concurrent AC and DC input. For
example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted Power Supply (UPS)
DC power.

Different expansion modules are interchangeable.
40GE
25GE
QSFP+
SFP28
Ports
Ports
N/A N/A
N/A N/A
24 N/A
Expansion Module
M6500-08CQ
M6500-24VS2CQ
100GE Expansion
QSFP28 Module
Ports Slots
N/A 4
8 N/A
2 N/A
Power Module
RG-PA800I-F or
RG-PD800I-F
1
Power Fan
Redundancy Redundancy
1+1 2+1
N/A N/A
N/A N/A
Fan Module
M6500-FAN-F
Overview
