SIEB & MEYER SD2S Hardware Description page 79

Code Error message
E39 Tracking error monitoring and mo-
(0x527) tor slowdown
(1319d)
E40 Motor feedback
(0x528)
(1320d)
E41 Motor phase lost
(0x529)
1 No motor connected
(1321d)
2 Wrong motor connected
E42 Overvoltage in DC link
(0x52A)
(1322d)
E43 Undervoltage in DC link
(0x52B)
(1323d)
E44 Commutation lost
(0x52C) The following list of error messages
(1324d) includes a note for which drive
function the error might appear.
1
▶
HSBLOCK
2
▶
FPAM
3
▶
SVC
4
▶
HSPWM
5
▶
VF
1
EMF monitoring
2
Flux monitoring
3
Overload current monitoring
4
Under flux monitoring
5
Minimum speed monitoring
2, 3
6
Error during alignment
7 Current limitation V/f oscil-
5
lates
E45 Short circuit in power output stage
(0x52D)
(1325d)
1 Internal short circuit
2 (VCE) desaturation detection
3 Short to ground
4 Current measuring range
5 Overload motor
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
Error reaction
Motor is stopped by current moni-
toring via short-circuit of the motor
(1)
phases.
Motor is stopped by current moni-
toring via short-circuit of the motor
(1)
phases.
Motor is stopped by current moni-
toring via short-circuit of the motor
(1)
phases.
Drive is immediately disabled, mo-
tor coasts to standstill.
Drive is immediately disabled, mo-
tor coasts to standstill.
Drive is immediately disabled, mo-
tor coasts to standstill.
1, 2, 3 4
4
4
4
1 ,
1, 2
Drive is immediately disabled, mo-
tor coasts to standstill.
Status Display and Error Messages
Possible reason
▶ Wrong parameters
▶ Motor connected incorrectly
▶ Mechanical problems
▶ Connection of motor feedback faulty
▶ Broken cable
Motor connection/configuration is faulty:
1 No motor connected / incorrect
wiring, broken cable
2 Wrong parameters
▶ No ballast resistor is connected or
ballast resistor is dimensioned too
small, i.e. X41/X63 not connected
▶ DC link not connected
▶ The error E44 is triggered in case of
wrong current feed of the motor dur-
ing operation without sensor.
▶ Faulty parameters entered for the
motor or faulty dimensioning of the
motor. The error depends on the dri-
ve function. For details refer to the
corresponding setup instructions.
Short circuit of the power output stage
due to:
1 Faulty drive control
2 Wrong parameters, output stage
defective, broken cable, short cir-
cuit etc.
3 Short to ground of a motor phase
4 Wrong parameters, output stage
defective, broken cable, short cir-
cuit etc.
5 Drive function V/f: incorrect para-
meter setting of "Flying restart"
79
