Digital Outputs- Vf - SIEB & MEYER SD2S Hardware Description

Connector Pin Assignment
Specification of terminal connections
▶
Conductor cross-section solid/stranded: 0.14 to 1.5 mm²
▶
Tightening torque: 0.22 to 0.25 Nm
Related topics
chapter 8.4.1 "Digital Outputs", page 50
7.7.2 Digital Outputs– VF
12-pole Mini-Combicon connector, suitable for mating connector MC 1,5/ 12-ST-3,81
(Phoenix)
Mating con- Pin I/O
nector X15
1 O
2 O
3 O
4 O
5 O
6 I
7 O
8 I
9 I
10 O
11 I/O
12 I/O
(1)
Parallel operation with other SD2S drive amplifiers or external components is not possible.
Specification of terminal connections
▶
Conductor cross-section solid/stranded: 0.14 to 1.5 mm²
▶
Tightening torque: 0.22 to 0.25 Nm
Related topics
Digital Outputs, page 50
NAMUR sensor, page 50
34
Name Configurable functions
▶ Ready type 1 (with power
OUT0
supply okay)
▶ Ready type 2 (without pow-
er supply okay)
OUT1
OUT2
OUT3
OUT4
IN8 / ▶ No function
▶ Error reset
PULSE IN
▶ External hardware OK
▶ Speed direction
▶ Teach no-load current
▶ Parameter set Bit 5
▶ MOP up
▶ MOP down
▶ NAMUR sensor; displayed, when motor feedback = NAMUR sensor
▶ Pulse generator 24 V; displayed, when motor feedback = Pulse genera-
tor 24 V
▶ Digital field plate / GMR; displayed, when motor feedback = Digital field
plate / GMR
PULSE OUT Speed pulses
VCC EXT 24 V logic supply in the event of an AC power failure (0.5 A)
VCC IO 24 V supply for the outputs
24 V auxiliary voltage for the outputs (24 V ±10 %, uncontrolled, max.
(1)
VCC OUT
0.25 A)
GND Ground
GND Ground
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
▶ No function
▶ M01 – Message power output stage
ready
▶ M02 – Message operation enabled
▶ M03 – Message drive error
▶ M10 – Ref. value reached
▶ M11 – Current limit reached
▶ M12 – Speed zero
▶ W04 – Power output stage load
▶ W05 – Motor load
▶ W07 – Motor temperature
▶ W09 – Undervoltage power output
stage
▶ W12 – Speed error
▶ W24 – Warning threshold 'current'
▶ W26 – Warning threshold 'overload
current'
(pin coded)
