D.1.4 Line Filters for Frequency Converter/Power Electronics

Line Filters by TDK & EPCOS Group
▶
1-phase and 3-phase line filters
▶
high attenuation
▶
partial RCD compatibility
Note
The maximum current (I
Note
When such a line filter is used, very high leakage currents occur because of Cy > 1.5 μF.
For this reason the line filter is only to a limited extent usable with an RCD (residual cur-
rent protective device).
You can order appropriate line filters by TDK & EPCOS Group at SIEB & MEYER. The
following table lists the article numbers:
SIEB & MEYER article number
35063080 (1-phase)
35063103 (3-phase)
35063106 (3-phase)
35063107 (3-phase)
35063115 (3-phase)

D.1.5 Mains Chokes

Note
Choose the mains choke according to the expected continuous current per mains
phase.
The following mains chokes by the company Block are available from SIEB & MEYER:
SIEB & MEYERarticle number
13015833
13015834
13015835
13015801
13015802
13015803
13015804
13015805
13015808
13015810
13015811
13015812
13015814
13015823
13015825
13015826
Manufacturers of mains chokes:
▶
http://www.block.eu
▶
http://www.enerdoor.de
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
) must be adapted to the back-up fuses of the device.
max
Rated current (I
20 A
50 A
90 A
120 A
220 A
Description
Mains choke: 1 × 6 A
Mains choke: 1 × 10 A
Mains choke: 1 ×16 A
Mains choke: 3 × 16 A, uk = 3 %
Mains choke: 3 × 25 A, uk = 3 %
Mains choke: 3 × 35 A, uk = 3 %
Mains choke: 3 × 40 A, uk = 3 %
Mains choke: 3 × 50 A, uk = 3 %
Mains choke: 3 × 80 A, uk = 3 %
Mains choke: 3 × 90 A, uk = 3 %
Mains choke: 3 × 100 A, uk = 3 %
Mains choke: 3 × 180 A, uk = 3 %
Mains choke: 3 × 250 A, uk = 3 %
Mains choke: 3 × 300 A, uk = 3 %
Mains choke: 3 × 500 A, uk = 3 %
Mains choke: 3 × 630 A, uk = 3 %
Manufacturers
) Leakage current
rated
(I )
leak
7.9 mA
15 mA
18 mA
18 mA
17 mA
