You can order the following materials at SIEB & MEYER:
Article
Polishing disk for optical fiber cables
Dismantling tool for optical fiber cables
Grinding paper
7.13 X44 – Mains Supply
Device variants:
0362x...
1-phase mains supply
3-phase mains supply
4-pole Power-Combicon connector, suitable for mating connector SPC 5/ 4-STCL-7,62
(Phoenix) with Click & Lock system (see
Mating con-
nector X44
3-phase mains supply of the device variants 0362x29xC / 0362x49xC
The devices must be supplied with max. 3 × 230 V
devices.
→ Use a suitable mains transformer for 3-phase supply to the device variants
0362x29xC / 0362x49xC (see connection examples
Specification of terminal connections:
▶
Conductor cross-section solid: 2.5 to 10 mm²
▶
Conductor cross-section stranded: 2.5 to 6 mm²
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
min. 7 mm
1 - 2 mm
SIEB & MEYER article number
47000001
47000002
47000003
29xF
–
✔
STCL (p.
Pin Coding 1-phase mains supply
Nam
e
1 Coded L
2 – N
3 – –
4 – PE
NOTICE
Connector Pin Assignment
3
4
49xF 29xC
✔
–
✔ ✔
30))
3-phase mains supply
Meaning Nam Meaning
e
Main supply L1 Main supply
Neutral conductor L2 Main supply
n.c. L3 Main supply
Protective conductor PE Protective conductor
. Higher voltages can destroy the
AC
page 70).
49xC
✔
✔
