Connector Pin Assignment
7.10
X18– Analog Interface
The available functions of the analog inputs and outputs are different depending on the
drive function. You can set the desired function in the software drivemaster2.
9-pole male D-sub connector
X18
Pin
I/O
1
I
2
I
3
I
4
I/O
5
6
O
7
I
8
O
9
O
(1)
The analog input AIN0+ (reference to ground) is also provided at connector X16/ pin 10.
Stud bolt flange: max. tightening torque = 0.7 Nm
Related topics
X18 – Analog Inputs/Outputs, page 67
40
Name
Configurable functions
SERVO / VECTOR (SVC)
AIN1-
Reference point of AIN1+ (pin 2)
▶ No function
AIN1+
▶ Speed reference value
(1)
AIN0+
▶ Current reference value
▶ Current limitation
▶ W24 – Warning threshold
'current'
GND
Ground
n.c.
▶ No function
AOUT1
▶ Target speed
▶ Speed reference value
▶ Speed actual value
▶ Speed error
▶ Current reference value
▶ Current actual value
▶ Motor temperature
▶ Power output stage tempera-
ture
▶ Motor load
▶ Power output stage load
▶ Voltage of the bus
▶ Active power
▶ DC link current Idc
AIN0-
Reference point for AIN0+ (pin 3)
▶ No function
AOUT0
▶ Target speed
▶ Speed reference value
▶ Speed actual value
▶ Speed error
▶ Current reference value
▶ Current actual value
▶ Motor temperature
▶ Power output stage tempera-
ture
▶ Motor load
▶ Power output stage load
▶ Voltage of the bus
▶ Active power
▶ DC link current Idc
VCC_10
10 V supply voltage
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
HSPAM / VF
▶ No function
▶ Speed reference value
▶ Current limitation
▶ W24 – Warning threshold 'current'
▶ No function
▶ Target speed
▶ Speed reference value
▶ Speed actual value
▶ Speed error
▶ Current reference value
▶ Current actual value
▶ Motor temperature
▶ Power output stage temperature
▶ Motor load
▶ Power output stage load
▶ Voltage of the bus
▶ Active power
▶ DC link current Idc
▶ No function
▶ Target speed
▶ Speed reference value
▶ Speed actual value
▶ Speed error
▶ Current reference value
▶ Current actual value
▶ Motor temperature
▶ Power output stage temperature
▶ Motor load
▶ Power output stage load
▶ Voltage of the bus
▶ Active power
▶ DC link current Idc
