Connector Meaning Description - SIEB & MEYER SD2S Hardware Description

Connector
X19 COM
X26 Rx
X27 Tx
X44
X45
X63
X64 OUT
X65 IN
SK 14
Note
You can order the appropriate connector kit for the device variants 0362x49xx and
0362129xx at SIEB & MEYER under article number 32299600.
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
Meaning
COM interface
SERVOLINK 4 optical input
SERVOLINK 4 optical output
Mains supply
Motor connection
External ballast resistor
EtherCAT slave output
EtherCAT slave input
Device housing ground
Mounting holes for shield connection clamp SK 14 by Phoenix
(comprised in connector kit)
Device Description
Description
page 41
page 41
page 41
page 43
page 44
page 45
page 45
page 73
page 72
29
