Mechanical installation conditions for the system according to DIN EN 61800-2:
„Vibrations must remain within the limit values of the IEC 60721-3-3, class 3M1, stan-
dard for fixed equipment."
Frequency [Hz]
Tab. 1: Vibration limits of the system
"Vibrations which exceed these limits, or the use on mobile equipment, are considered
as abnormal mechanical conditions."
Operating conditions:
The following requirements are to be considered for the installation and the operation of
the device. Noncompliance with theses requirements is regarded as abnormal operat-
ing condition:
▶
The device is conceived according to DIN EN 61800-2 for the dirt level 2. That
means: Ensure to avoid conductive impurities during the operation.
▶
Devices with air cooling only can be loaded to their maximum up to a height of
1000 m above MSL (3281 ft above MSL). For an operation in areas higher than
1000 m (3281 ft) above MSL the capacity must be reduced by 1.5 % per 100 m
(328 ft).
The maximum site altitude is 2000 m (6562 ft) above MSL.
▶
The device must be protected against harmful gas, oil vapor and salty air at the
place of installation.
▶
The ambient air must not contain aggressive, grinding, electrically conductive or
flammable substances as well as any amount of dust.
▶
The maximum relative humidity during operation is 85 % (no condensation).
▶
The allowed ambient temperature for the operation is +5 °C to +40 °C (+41 °F to
+104 °F). Extreme and sudden changes of the temperature should be prevented.
– Ensure power derating for devices used in ambient temperatures over +40 °C
(+104 °F) (see technical data). The following applies: -1.5 % per 1 °C. Note:
F=C×9/5+32; C=(F-32)×5/9
– Devices with polyester films: The polyester films must not be exposed to direct
sunlight for extended periods of time. In conditions of high humidity (>80 %) the
ambient temperature must not exceed +40 °C (+104 °F). The polyester films
must not come in contact with benzyl alcohol or methylene chloride.
▶
Make sure that the aeration elements are free and open, so that the air circulation
is not restricted.
Drive System SD2S - Hardware Description 0362x49xx / 0362129xx
2 ≤ f < 9
9 ≤ f < 200
Safety Instructions
Amplitude [mm]
1,5
Not applicable
Acceleration [m/s²]
Not applicable
5
15
