3.2
Illustrations
Introduction
This section provides illustrations of the ÄKTA readyflux system. The main features and
components are indicated.
ÄKTA readyflux overview
The illustration below shows the ÄKTA readyflux system.
Part
1
2
3
4
5
ÄKTA readyflux Operating Instructions 29175550 AG
Function
Cabinet transfer side
Cabinet permeate side
Top panel
Front panel
Swivel casters with brake
3 System description
3.2 Illustrations
