Step
2
3
4
5
Note:
Prepare for the NFF flow kit
installation test
Follow the steps below to prepare for the NFF flow kit installation test.
Step
1
2
3
ÄKTA readyflux Operating Instructions 29175550 AG
Action
For ½ inch and ⅜ inch flow kits, connect 1/2ʺ i.d. flexible tubing on XV-001
and 3/8ʺ i.d. flexible tubing on XV-034 (P-203 or AE-131) outlet and place it
in the test solution container.
For ¼ inch flow kits, connect 1/4ʺ i.d. flexible tubing on XV-001 and 1/4ʺ i.d.
flexible tubing on XV-034 (P-203 or AE-131) outlet and place it in the test
solution container.
Open the lid of permeate pump (P-203).
Place the container next to the system and use only required tubing lengths
to connect the flow kit and the container.
For a description on how to make the connection, see
connections of the flow kit using TC end connectors on page
Follow the instructions on the screen.
The following warnings can appear during the test and can be ignored:
• The UV led low light intensity warning appears if UV is enabled and the
lamp is not switched on.
• The FE141 measurement error warning appears if there is no liquid or air
bubble is detected by the FE-141.
WARNING
Overpressure. Do not block the outlet tubing with, for instance,
stop plugs. Blocked outlet tubing can create overpressure and can
result in injury.
Action
Directly connect the feed outlet to the flow kit permeate inlet.
Connect 1/2ʺ i.d. flexible tubing on XV-001 and 3/8ʺ i.d. flexible tubing on
XV-033 outlet and place it in the test solution container.
Place the container next to the system and use only required tubing lengths
to connect the flow kit and the container.
For a description on how to make the connection, see
connections of the flow kit using TC end connectors on page
5 Operation
5.2 Flow kit installation
5.2.5 Flow kit installation test
Connect the end
147.
Connect the end
147.
