Figure 16 shows an array that has its primary disk drives (pdisk2, pdisk3, pdisk10 and
pdisk11) in building 1, and its secondary disk drives (pdisk5, pdisk6, pdisk7 and pdisk8)
in building 2. Pdisk1 and pdisk4 have been assigned as hot spare disk drives, but no
hot spare pool has been defined.
Building 1
pdisk1
A
(Spare)
D
A
P
T
E
R
pdisk12
Figure 16. Primary Disks in Building 1; Secondary Disks in Building 2
46
User's Guide and Maintenance Information
pdisk2 pdisk3
pdisk11 pdisk10
Primary Disks
Building 2
pdisk4 pdisk5
(Spare)
pdisk9 pdisk8
Secondary Disks
pdisk6
A
D
A
P
T
E
R
pdisk7
