Two Loops with One Adapter
If only one SSA adapter is contained in the SSA loops, the adapter can provide support
for up to 96 disk drives (a maximum of 48 per loop).
Figure 8 shows an example configuration that has two loops and one adapter:
Adapter
Figure 8. Two Loops with One Adapter
14
User's Guide and Maintenance Information
SSA Disk Drives
