IBM Flex System EN4132 2-port 10Gb Ethernet
Adapter
IBM Redbooks Product Guide
The IBM Flex System™ EN4132 2-port 10Gb Ethernet Adapter delivers high-bandwidth and
industry-leading Ethernet connectivity for performance-driven server and storage applications in
enterprise data centers, high-performance computing (HPC), and embedded environments. Clustered
databases, web infrastructure, and high frequency trading are just a few applications that achieve
significant throughput and latency improvements, resulting in faster access, real-time response, and more
users per server. Based on Mellanox ConnectX-3 EN technology, this adapter improves network
performance by increasing available bandwidth while decreasing the associated transport load on the
processor.
The following figure shows the IBM Flex System EN4132 2-port 10Gb Ethernet Adapter.
Figure 1. IBM Flex System EN4132 2-port 10Gb Ethernet Adapter
Did you know?
Mellanox networking adapters deliver industry-leading bandwidth with ultra low, sub-microsecond latency
for performance-driven server clustering applications. Combined with the IBM Flex System Fabric
EN4093 10Gb Scalable Switch, your organization can achieve efficient computing by off-loading the
processor protocol processing and data movement overhead, such as RDMA and Send/Receive
semantics, allowing more processor power for the application.
IBM Flex System EN4132 2-port 10Gb Ethernet Adapter
1

Advertisement

loading

  Also See for IBM Flex System EN4132

  Related Manuals for IBM Flex System EN4132

  Summary of Contents for IBM Flex System EN4132

  • Page 1 The following figure shows the IBM Flex System EN4132 2-port 10Gb Ethernet Adapter. Figure 1. IBM Flex System EN4132 2-port 10Gb Ethernet Adapter Did you know? Mellanox networking adapters deliver industry-leading bandwidth with ultra low, sub-microsecond latency for performance-driven server clustering applications.
  • Page 2: Part Number Information

    10 and up to 127 virtual machines, this adapter can satisfy the bandwidth demands of a virtualized environment. Features The IBM Flex System EN4132 2-port 10Gb Ethernet Adapter has the following features: RDMA over Converged Ethernet  ConnectX-3 uses IBTA RoCE technology to provide efficient RDMA services, delivering low-latency and high-performance to bandwidth and latency sensitive applications.
  • Page 3: Specifications

    This powerful combination of QoS and prioritization provides fine-grained control of traffic, ensuring that applications run smoothly. Specifications The IBM Flex System EN4132 2-port 10Gb Ethernet Adapter has the following specifications: Based on Mellanox Connect-X3 technology  Virtual Protocol Interconnect (VPI) ...
  • Page 4: Supported Servers

     Remote boot over Ethernet  Remote boot over iSCSI  Supported servers The following table lists the IBM Flex System compute nodes that support the EN4132 2-port 10Gb Ethernet Adapter. Table 2. Supported servers Description Part number x220 x240...
  • Page 5: Supported I/O Modules

    Table 3. I/O modules supported with the EN4132 2-port 10Gb Ethernet Adapter Supports the Description Part number EN4132 adapter IBM Flex System Fabric CN4093 10Gb Converged Scalable Switch 00D5823 IBM Flex System Fabric EN4093R 10Gb Scalable Switch 95Y3309 IBM Flex System Fabric EN4093 10Gb Scalable Switch...
  • Page 6: Supported Operating Systems

    SUSE LINUX Enterprise Server 11 for AMD64/EM64T  SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T  VMware ESX 4.1  VMware ESXi 4.1  VMware vSphere 5  VMware vSphere 5.1  IBM Flex System EN4132 2-port 10Gb Ethernet Adapter...
  • Page 7: Regulatory Compliance

    Weight: 13 g (0.3 lb)  Shipping dimensions and weight (approximate): Height: 58 mm (2.3 in.)  Width: 229 mm (9.0 in.)  Depth: 208 mm (8.2 in.)  Weight: 0.4 kg (0.89 lb)  IBM Flex System EN4132 2-port 10Gb Ethernet Adapter...
  • Page 8: Popular Configurations

    EN4093 10Gb Scalable Switch. The following figure shows one EN4132 adapter installed in slot 2 an x240 Compute Node, which in turn is installed in the chassis. Two IBM Flex System Fabric EN4093 10Gb Scalable Switches are installed in I/O bays 3 and 4.
  • Page 9: Related Publications

     http://www.ibm.com/support IBM Flex System Interoperability Guide  http://www.ibm.com/support IBM Flex System Products and Technology , SG24-7984  http://www.redbooks.ibm.com/abstracts/sg247984.html IBM Redbooks® Product Guides for IBM Flex System servers and options  http://www.redbooks.ibm.com/portals/puresystems IBM Flex System EN4132 2-port 10Gb Ethernet Adapter...
  • Page 10 Web sites. The materials at those Web sites are not part of the materials for this IBM product and use of those Web sites is at your own risk.IBM may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.
  • Page 11 (® or ™), indicating US registered or common law trademarks owned by IBM at the time this information was published. Such trademarks may also be registered or common law trademarks in other countries. A current list of IBM trademarks is available on the Web at http://www.ibm.com/legal/copytrade.shtml...
