80 Panel Functions
_______________________________________________________________________________________________
Example for shifting the image to the Y-direction:
Image shifting to the Y-direction
Printout after the image
shifting to the Y-direction.
In this example the value of the
Image Y-Position was increased
(UP key).
________________________________________________________________________________________________
MICROPLEX
Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es
Operator's Manual SOLID 60E-2
Feed
direction
(print
direction)
Previous position of the
printout margin (prior to
the image shifting)
