Transport path
Green
lever
________________________________________________________________________________________________
MICROPLEX
Mantenimiento Periféricos Informáticos SL C/Canteras, 15 28860 Paracuellos de Jarama Tel: 00 34 917481604 WEB: https://mpi.com.es
3. Turn the green lever at the transport unit counterclockwise
downwards. The transport path will be shifted down. Do not pull
out the transport unit.
4. Look for jammed paper in the transport unit.
5. Rotate the turning knob "B" 90° clockwise (free) to set
the scuff roller to the "open" condition.
Fuser unit
Knob B
Transport unit
Operator's Manual SOLID 60E-2
Troubleshooting 139
Transport
unit
