Mycom CLM 152
Post and panel mounting (mounting version B)
Attach the parts of the mounting kit supplied
with mounting version B to the housing rear
as depicted in Fig. 4.5:
Cut-out required:
161
Installation depth:
Pipe diameter:
Caution:
You must use the CYY 101 weather
protection cover for installation
outdoors (see Mounting accessories)
➀
Mounting accessories
CYY 101 weather protection cover for
operating the Mycom CLM 152 outdoors. The
post mounting kit for the weather protection
cover is also required for installing on vertical
or horizontal pipes (Fig. 4.5).
Material: stainless steel
Order No. CYY101-A
Round post mounting kit for CYY 101 weather
protection cover for attachment to vertical or
horizontal pipes with diameters up to 70 mm.
Material: stainless steel
Order No. 50062121
Endress+Hauser
+0,5
+0,5
x 241
mm
134 mm
max. 70 mm
➁
MONTAGE.CDR
300
M6
70
90
Installation
lm152e04.chp
Mounting kit for panel
mounting and post
mounting
Fig. 4.5
(Order No. 50061357)
MASTBEF.CDR
Panel mounting ➀ and
post mounting ➁
Fig. 4.2
Mycom CLM 152
270
YH-101-6.CDR
Fig. 4.3
Weather protection cover
CYY 101 round post
attachment for weather
Fig. 4.4
protection cover
yh-101-7.cdr
11
