Instrument configuration
52
7.6

Substance selection / Concentration measurement

→ Instrument data
PARAM
Function
Select measuring range with
remote switch-over activated
Select substance
Enter substance name
Enter number of support points for
substance concentration curve
A specific concentration is
assigned to a conductivity value
1
at every support point
Enter number of support points for
Tc table
A temperature coefficient is
assigned to a temperature value
2
for each support point
1
Concentration values:
The entered values must be strictly monotonic increasing or decreasing.
Conductivity values:
The entered values must be strictly monotonic increasing or decreasing. They must have a
minimum distance.
a) If the successive conductivity values are in the same switching range, then the minimum
distance is 0.5 % of the end value of the switching range.
b) If the successive conductivity values are in different switching ranges, then the minimum
distance is 0.5 % of the end value of the higher switching range.
If the mininum distance is not reached, then an error message is given and the table is
marked as invalid.
Switching range
0.0 ... 200.0 nS/cm
0.200 ... 2.000 µS/cm
2.00 ... 20.00 µS/cm
20.0 ... 200.0 µS/cm
After entry of a substance table, the table elements are checked for validity. The concentration
and conductivity values are checked separately.
2
The temperature values must be entered strictly monotonic increasing and with a difference of
minimum 10 K. The Tc values are not subject to check. After entry of a Tc table, it is checked
for validity.
→ Substance
selection
Measuring range 1 ... 4
NaOH
}
HNO3 (fixed, no further
H3PO4
H2SO4
USER1 ... USER4 (freely selectable)
Für USER1 ... USER4
Substance name, max. 5 chars.
0 ... 9; a ... Z
Support point substance curve,
2 ... 10
Concentration
00.00 %
Support points for Tc table, 2 ... 10
Temperature
000.0 °C
Minimum distance Switching range
1 nS/cm 200 ... 2000 µS/cm
10 nS/cm 2.00 ... 20.00 mS/cm
100 nS/cm 20.0 ... 200.0 mS/cm
1 µS/cm 200 ... 2000 mS/cm
Mycom CLM 152
Note:
This menu only appears when the
concentration measurement is set as
the measuring type (see Parameter
menu, Chap. 7.1.1).
Selection Factory setting
Measuring
range 1
settings required) NaOH
USER 1
2
Conductivity
0.000 mS/cm
2
Temp. coefficient
00.00 %/K
Minimum distance
10 µS/cm
100 µS/cm
1 mS/cm
10 mS/cm
