Installation
Wiring diagram for
Fig. 4.15 CLM 152-Z (base version)
18
Conductivity input module (Ex) i
FCL1 (Slot 1)
Temperature Conductivity
ϑ
Con
11 12 13 14 15 16 17
bl rt rt bl
Pt 100
14 15 16 17
n.c. n.c.
conductive
FCL1 module (slot 1, basic configuration):
11 Pt 100 terminal, sensor line
12 Pt 100 terminal, sensor line
13 Cable compensation terminal
For inductive sensor
14 Transmitter coil inner conductor
15 Transmitter coil screen
16 Receiver coil screen
17 Receiver coil inner conductor
For conductive sensor
14 Electrode cable screen
15 not connected
16 not connected
17 Electrode cable inner conductor
Connection data for power circuits,
terminals 11 to 17:
C = 50 nF
a,max
= 100 µH
L
a,max
Current output module (Ex) i
FCYI (Slot 2)
Conductivity Temperature
ϑ
Con
mA mA
31 32 33 34
+ +
-
-
Only
two-electrode
sensors
connectable
FCYI module (slot 2, basic configuration):
Active current output:
31
32
33
34
Connection data for power circuits,
terminals 31 to 34:
U
max
P
max
C
a,max
Terminal blocks (basic configuration):
Power supply:
L
N
PE
Output contacts:
85
86
87
88
Mycom CLM 152
Basic module
Fail Contact 1 Aux. voltage
85 86 87 88 L
- - L+ L
Current output (Cd signal) positive
Current output (Cd signal) negative
Current output (temp. signal) positive
Current output (temp. signal) negative
= 16.4 V I = 65 mA
max
= 1.1 W
= 100 µH
= 40 nF L
a,max
AC voltage, phase
AC voltage, neutral
Protective earth
Alarm contact +
Alarm contact –
Contact 1 +
Contact 1 –
Endress+Hauser
N PE (AC)
-
(DC)
