Installation

Dimensions for wall
Fig. 4.1 mounting
10
4 Installation
4.1

Storage and transport

The packaging material used to store and
transport the instrument must provide shock
and moisture protection. The original
packaging materials provide the most
4.2

Unpacking

Make sure the contents are undamaged. The
post office or the freight carrier must be
informed of any damage and the supplier
must be notified.
Check the scope of delivery against your
purchase order and the shipping documents:
• Scope of delivery
• Instrument model and version as specified
on nameplate (see Fig. 3.3)
• Accessories (see Chapter 3.7)
• Operating instructions
4.3 Installation
Wall installation (mounting versions A and B)
142
167
PM152WAN.CDR
Insert the screws in the attachment holes of
the instrument and mount the instrument as
depicted in Figure 4.1.
effective protection. The ambient conditions
must also meet the requirements (see
Technical data).
Keep the original packaging materials in case
the instrument has to be stored or shipped at
a later date.
If you have any questions, please contact
your supplier or the Endress+Hauser sales
agency (see rear page of this document).
Plastic
caps
100
∅ 6 mm
Fixing screw:
∅ 8 mm
Rawl plug:
The holes are covered with plastic caps.
Mycom CLM 152
Endress+Hauser
