Endress+Hauser Mycom CLM 152 Operating Instructions Manual page 15

Mycom CLM 152
4.4.1 Connecting the Mycom CLM 152 in non-hazardous area
FCL1
Conductivity input module FCL 1
(Slot 1)
Temperature Conductivity
ϑ
Con
11 12 13 14 15 16 17
bl rd rd bl
Pt 100
14 15 16 17
n.c. n.c.
conductive
FCL1 module (Slot 1, basic configuration):
11 Pt 100 terminal, sensor line
12 Pt 100 terminal, sensor line
13 Cable compensation terminal
Inductive sensor
14 Transmitter coil inner conductor
15 Transmitter coil screen
16 Receiver coil screen
17 Receiver coil inner conductor
Conductive sensor
14 Electrode cable screen
15 not connected
16 not connected
17 Electrode cable inner conductor
Endress+Hauser
88 87 85 86
31 32 33 34
I I
1 2
mA mA
Basic module
Conductivity Temperature
ϑ
Con
mA mA
31 32 33 34 85
− −
+ +
Only
two-electrode
sensors
connectable
Terminal blocks (basic configuration):
Power supply:
L/L+
N/L–
PE
Active current output:
31
32
33
34
Output contacts:
85
86
87
88
F101
250 Vac / 2A
( cos =1)
125 Vdc / 3A
L L N
L+ L+ L –
Relay
contact
Power
Analog out
supply
0/4...20mA
max. 600
PE
Fail Contact 1 Aux. voltage
86 87 88 AC: L L
DC: L+ L+
AC voltage, phase or DC +
AC voltage, neutral or DC –
Protective earth
Current output (Cd signal) positive
Current output (Cd signal) negative
Current output (temp. signal) positive
Current output (Temp. signal) negative
Alarm contact
Alarm contact
Contact 1
Contact 1
Installation
lm152e04.chp
Wiring compartment of
Mycom CLM 152 non-Ex
Fig. 4.6 (base version)
LM152AR.CDR
N PE
L–
Wiring diagram of Mycom
Fig. 4.7 CLM 152 (base version)
LM152CON.CDR
13
