Instrument configuration
Current output signal
Fig. 7.2 with linear characteristic
42
Definition of parameter for second
current output (only for instrument
with 2nd Cond. input)
Measuring current range
Output damping
Setting options for Temp. 1 or Temp. 2 (for differential measurement)
Measuring range lower limit
Measuring range upper limit
Enter measuring range limits
dependent on selected characteristic
1)
0.00 mA at measuring current range 0 ... 20 mA
2.40 mA at measuring current range 4 ... 20 mA
2)
22.00 mA
The current output signal characteristic can
be matched to the requirements of the
downstream signal processing, display or
recording equipment.
The allocation of the measured value to the
current output signal depends on the internal
measuring ranges of the instrument and the
characteristic curve you select.
A) Linear current output signal characteristic
20
12
(10)
4
(0)
0
Current output 2
Cond. 1, Cond. 2,
Temperature 1, Temperature 2
0 ... 20 mA or 4 ... 20 mA
1.0 ... 20.0 mA/s
Temperature: –35.0 ... +250.0 °C
Temperature: –35.0 ... +250.0 °C
Setting options for Cond.1 or Cond.2
Setting options and factory settings
see under A) to D) (next page)
Choose between the following characteristics:
A)
B)
C)
D)
20 40 60
Mycom CLM 152
Temperature 1
4 ... 20 mA
20.0 mA/s
0.0 °C
200.0 °C
linear
bilinear
logarithmic
Table (freely programmable
current output characteristics
Values in brackets for
current output 0...20 mA
80 100
Current output meas. range [%]
