Mycom CLM 152
FCXI additional module:
Comprising two contact inputs for Hold,
remote measuring range switch-over and
analogue input with measuring transmitter
power supply.
21 Current input, positive
22 Current input, negative
81 Contact input 1
82 Contact input 1
83 Contact input 2
84 Contact input 2
Intrinsically safe ia/ib circuit 1:
Voltage supply
Current drain
Intrinsically safe ia/ib circuit 2:
Voltage supply
Current drain
The parallel switching of the two input circuits is permitted (Tl. 81/82 and
83/84) to power the contact inputs from only one intrinsically safe circuit.
Intrinsically safe ia/ib circuit,
Maximum load 500 Ω
FCYP additional module
PROFIBUS-PA digital port:
98 PA–
99 PA+
Endress+Hauser
Analogue/contact input module
Switch 1
U = 4 ... 30 V
0
@ 30 V, max. 100 mA
Switch 2
U = 4 ... 30 V
0
@ 30 V, max. 100 mA
Ca,max = 40nF
Current input Contact inputs
mA
21 22 81 82 83
Kl. 81
Ci,max = 15 nF
Li,max = 53 µH
Kl. 82
Kl. 83
Ci,max = 15 nF
Li,max = 53 µH
Kl. 84
+
Kl. 21
U ,max = 22.0 V
0
I ,max = 50 mA
0
P ,max = 640 mW
a
Kl. 22
®
PROFIBUS module
(Ex) i
99 98
Installation
lm152e04.chp
84
Connection of
Fig. 4.21 FCXI module
fcxicon.cdr
+
+
External wiring of input
asx_fcxi.cdr
Fig. 4.22 circuits on FCXI module
Connection of
Fig. 4.23 FCYP module
profibus.cdr
