Mycom CLM 152
7.1

System configuration

PARAM
→ Instrument data
→ System configuration
→ Measured variable
→ Code
→ Output contacts
→ General settings
7.1.1 Measured variable
Function
Select measuring type
Select sensor
Differential or single-circuit
measurement
(only on instruments with two
measuring channels)
Select unit
Select temperature sensor 1
Select temperature sensor 2
(only for difference)
Configure input
contacts (only for FCXI expansion
module, remote measuring range
switch-over see 7.1.2)
*)
Only in relay configuration with Clean function!
Endress+Hauser
7.1.1
7.1.3
7.1.4
7.1.5
Selection
Conductivity, concentration, not
selectable with differentiation),
resistance
CLS 50, CLS 52,
2-ring: k = 0,01; k = 0,1; k = 1; k = 10
Differential measurement,
Single-circuit measurement
(mS / cm), (mS / cm) / (mS / m), (S / m)
(kΩ cm), (MΩ cm) / (Ω m), (kΩ m)
PT 100
PT 1000
NTC 30 kΩ
PT 100
PT 1000
NTC 30 kΩ
2 x hold,
1 x hold / 1 x remote-switch-over
2 x remote-switch-over
*)
external Clean control
Instrument configuration
Factory setting
Conductivity
CLS 52 for CD, conc.
2-ring k = 0,01 for
resistance
Differential
measurement
(µS / cm), (mS / cm)
for CD, conc.
(kΩ cm), (MΩ cm)
for MOhm
PT 100
PT 100
2 x hold
lm152e07.chp
35
