Appendix
General data
Limit and alarm functions
Electrical connection data
Temperature measurement
Concentration measurement
82
13.1.4 General technical data
Manufacturer
Instrument name
Function
Function type
Setpoint settings (in absolute values)
Hysteresis for switch contacts (in absolute figures)
On / off delay
Alarm threshold
Alarm delay
Power supply AC
Frequency
Power supply DC
Power consumption
Contact outputs (optional)
Switching current
Switching voltage
Switching power
Signal outputs
Isolation voltage
Current output
Current range
Measurement deviation
Load
Terminals, maximum cable cross-section
Temperature sensor
Measuring range (MR, also displayable in °F and K)
Measured value resolution
Measurement deviation at temp. output (as per IEC 746)
Reproducibility
Temperature signal output transfer range
Selection Conductivity range
NaOH
HNO
3
H SO
2 4
H PO
3 4
2)
USER 1 ... 4
Endress+Hauser
Mycom CLM 152
Limit contactor
MIN or MAX
0 ... 100 % of display range
1 ... 10 % of display range
0 ... 7200 s
0.5 ... 100 % of display range
0 ... 6000 s
24 / 100 / 115 / 200 / 230 V +10 / –15 %
47 ... 64 Hz
24 V, +20 / –15 %
max. 10 VA
Floating change-over contacts (Ex version: optocoupler)
switchable as NO or NC contact
max. 3 A
max. 250 VAC / 125 VDC
max. 750 VA
2 x 0 / 4 ... 20 mA, electrically isolated from other circuits,
but not between outputs
276 V
rms
0/4 ... 20 mA
≤ 0.2 % of upper range value
max 600 Ω
2
2,5 mm
Pt 100 (three-wire circuit)
–35 ... +250 °C
0.1 °C
0 ... 100 °C: ± 0.5 K; remaining range: ± 1 K
max. 0.1 % of MR
adjustable ∆ 28.5 ... ∆ 285 °C
0.0 mS/cm ... 410 mS/cm
0.0 mS/cm ... 781 mS/cm
0.0 mS/cm ... 723 mS/cm
0.0 mS/cm ... 73 mS/cm
0.0 µS/cm ... 2000 mS/cm
Mycom CLM 152
Concentration
0 ... 15%
0 ... 20 %
0 ... 20 %
0 ... 12 %
0 ... 99.99 %
Specifications subject to change
