Mycom CLM 152
Select »Maintenance«
Failure contact
Failure
Tl. 85/86
Contact 1
Maintenance required
Tl. 87/88
Relay contact of non-Ex version on power failure:
1)
active (NO contact closed, NC contact open)
2)
passive (NO contact open, NC contact closed)
Contact assignment when FYCK expansion module equipped
»NAMUR«,
Select
Limit
Failure contact
Failure
Tl. 85/86
Contact 1 Maintenance
Tl. 87/88 required
Contact 2 Function
2)
Tl. 89/90 check
Contact 3 Limit
Tl. 91/92 contact 1
Contact 4 Limit
Tl. 93/94 contact 2
Relay contact of non-Ex version on power failure:
1)
active (NO contact closed, NC contact open)
2)
passive (NO contact open, NC contact closed)
See also page 37
Hinweis:
The »fault contact« is active in case
of system faults and defects
(error codes 1 to 23) which can
cause the instrument to fail.
The preset error current is output at
current outputs 1 and 2
(see Chapter 7.2.1).
The fault contact is defaulted for all
settings.
The »maintenance contact«, if
configured, signals faults in the
instrument or process.
Operation can continue but the
measuring system will then require
an inspection.
Endress+Hauser
Contact assignment in base version
Select »Limit«
1)
Failure
2)
Limit contact
»NAMUR«
/ Maintenance
MR switch- / limit / MRS
over
1) 1)
Failure Failure
Maintenance Maintenance
2) 2)
required required
Function Limit
2)
check contact
2) 2)
MRS 1 MRS 1
2)
2)
MRS 2 2) MRS 2
2)
Select »USP«
1)
Failure
2)
1 x limit 2 x limit
Chemoclean Chemoclean
1) 1)
Failure Failure
Maintenance Limit
2) 2)
required contact 1
Limit Limit
2) 2)
contact contact 2
3) 3)
Water Water
Clean. Clean.
3) 3)
agent agent
Depending on the configuration in
7.1.4 the maintenance contact is
signalled in fault codes
30 to 52 or 30 to 78.
The »function check« contact is
active in Hold state and when
settings are made to the instrument
(e.g. during calibration and
configuration).
Instrument configuration
1)
2)
USP
NAMUR /
limit / USP
1) 1)
Failure
Maintenance
2) 2)
required
Function
2) 2)
check
Limit
2)
contact
2)
USP
