Mycom CLM 152
24
5

First start-up

5.1

Measures before first power-up

Before switching on the measuring
transmitter for the first time, familiarise
yourself with the operating instructions!
Caution:
Before switching on, check that all
the connections are in order!
Make sure the sensor is placed in
the medium or in a calibration
solution, otherwise it will display
implausible readings.
5.2 The „Start-up menu"
When the instrument is powered up for the
first time, it displays the „Set-up" menu. The
menu requests all the set-up data required for
operation. This automatically ensures that the
necessary set-up data is complete.
First the system requests you to select a
language for displaying the user interface.
A list is presented. If you select the line
„English", the line is displayed in inverse
video. Confirm your choice by pressing "E"
("Enter").
Your choice is accepted and the next request
is displayed.
Go through all the other requests in the same
way (cf. Chapter 6, „Operation").
Warning:
Before power-up, make sure that
there is no risk of damage to the
system in which the instrument is
integrated; e.g. valves, pumps or
similar that could become activated
unintentionally.
• End Start-up by pressing CAL, DIAG,
MEAS and PARAM.
• The start-up routine is repeated every time
the instrument is switched on until the
procedure has been completed once and
you have confirmed by pressing "Close" in
the last field.
• Then to access the Start-up routine, you
must select the menu structure using the
specialist code.
First start-up
Endress+Hauser
