Connecting Conductivity Sensors - Endress+Hauser Mycom CLM 152 Operating Instructions Manual

Installation
Inductive sensor
with connecting cable
Fig. 4.24 (here CLS 52)
Make-up of special
measuring cables
CYK 71 (left) and
Fig. 4.25 CLK 5 (right)
22
4.5

Connecting conductivity sensors

Inductive sensors
Conductivity sensors are connected via
special multi-core, screened measuring cable.
If you need to extend the measuring cables,
use the VBM junction box.
Make-up and termination of measuring cable
Semiconductor
screen
Inner conductor
green (11)
white (12)
yellow (13)
(17)
(14)
Screen
black
green (11)
white (12)
yellow (13)
brown
CYK 71 (unassigned)
Mycom CLM 152
Caution:
Make absolutely sure you protect
plugs and terminals from moisture.
Moisture leads to inaccurate
measuring results!
bl
Coax inner 17
rd
Coax screen 16
rd
red
Coax screen 15
white
bl
Coax inner 14
yellow
13
white
12
green
11
(14)
(17)
Semiconductor
(16)
(15)
(unassigned)
CLK 5
Endress+Hauser
anschl52.cdr
screen
red
white
brown
KABEL.CDR
