Installation
Connection of
Fig. 4.8 FCL1 module
14
Note:
•
The contact position on mains
failure or when a fault occurs can
be set for "contact 1" and "alarm
contact" through the system
configuration.
FCL1 additional module:
For second conductivity input.
11 12 13 14 15 16 17
bl rd rd
Pt 100
14 15 16 17
n.c. n.c.
fcl1.cdr
11
12
13
For inductive sensor
14
15
16
17
bl
For conductive sensor
inductive
14
15
16
17
conductive
Measuring channel allocation
Cond.1 / temperature 1
Only
two-electrode
Cond.2 / temperature 2
sensors
connectable
Mycom CLM 152
Note
•
All switching contacts are
interference-suppressed.
External loads must also be
interference-suppressed.
Pt 100 terminal, sensor line
Pt 100 terminal, sensor line
Cable compensation terminal
Transmitter coil inner conductor
Transmitter coil screen
Receiver coil screen
Receiver coil inner conductor
Electrode cable screen
not connected
not connected
Electrode cable inner conductor
Slot 1
Slot 2
