Mycom CLM 152
6
3.6

Instrument variants

You can identify the instrument variant and
the required power supply from the order
code on the nameplate.
CLM 152 conductivity and resistance measuring transmitter
Field housing, ingress protection IP 65, for wall mounting
Signal outputs 0 / 4 ... 20 mA for conductivity / resistance and temperature, 2 output contacts
Equipment and certificate
1-circuit version for non-hazardous areas
A1A Basic version
A1B 3 relays (Chemoclean)
A1C feedback/hold contact / remote MR switching
A1D 3 relays / feedback/hold contact (Autoclean) / remote MR switching
®
A1E PROFIBUS
A1F 3 relays (Chemoclean), PROFIBUS
A1G feedback/hold contact / remote MR switching, PROFIBUS
A1H 3 relays / feedback/hold contact (Autoclean) / remote MR switching, PROFIBUS
2-circuit version for non-hazardous areas
A2A Basic version
A2B 3 relays (Chemoclean)
A2C feedback/hold contact / remote MR switching
A2D 3 relays / feedback/hold contact (Autoclean) / remote MR switching
®
A2E PROFIBUS
A2F 3 relays (Chemoclean), PROFIBUS
A2G feedback/hold contact / remote MR switching, PROFIBUS
1-circuit version for Ex areas (CENELEC)
Z1A Basic version, EEx em [ia/ib] IIC T4
Z1B 3 optocouplers (Chemoclean), EEx em [ia/ib] IIC T4
Z1C feedback/hold contact / remote MR switching, EEx em [ia/ib] IIC T4
Z1D 3 optocouplers / feedback/hold contact (Autoclean) /
remote MR switching, EEx em [ia/ib] IIC T4
®
Z1E PROFIBUS
Z 1F 3 optocouplers (Chemoclean), PROFIBUS
Z1G feedback/hold contact / remote MR switching, PROFIBUS
2-circuit version for Ex areas (CENELEC)
Z2A Basic version, EEx em [ia/ib] IIC T4
Z2B 3 optocouplers (Chemoclean), EEx em [ia/ib] IIC T4
Z2C feedback/hold contact / remote MR switching, EEx em [ia/ib] IIC T4
®
Z2E PROFIBUS
1-circuit version for Ex areas (CSA)
C1A Basic version, NI with IS outputs Cl. I-III Div. 2, Group A-G
C1B 3 optocouplers (Chemoclean), NI with IS outputs Cl. I-III Div. 2, Group A-G
C1D 3 optocouplers / feedback/hold contact (Autoclean), remote MR switching,
NI with IS outputs Cl. I-III Div. 2, Group A-G
C1G feedback/hold contact / remote MR switching, PROFIBUS
NI with IS outputs Cl. I-III Div. 2, Group A-G
2-circuit version for Ex areas (CSA)
C2B 3 optocouplers (Chemoclean), NI with IS outputs Cl. I-III Div. 2, Group A-G
1-circuit version for Ex areas (FM)
F1A Basic version, NI outputs Cl. I Div. 2, Cl. II/III Div. 1, Cl. I Zone 2
F1B 3 optocouplers (Chemoclean), NI outputs Cl. I Div. 2, Cl. II/III Div. 1, Cl. I Zone 2
F1D 3 optocouplers / feedback/hold contact (Autoclean), remote MR switching,
NI outputs Cl. I Div. 2, Cl. II/III Div. 1, Cl. I Zone 2
F1G feedback/hold contact / remote MR switching, PROFIBUS
NI outputs Cl. I Div. 2, Cl. II/III Div. 1, Cl. I Zone 2
2-circuit version for Ex areas (FM)
F2B 3 optocouplers (Chemoclean), NI outputs Cl. I Div. 2, Cl. II/III Div. 1, Cl. I Zone 2
1-circuit version for Ex areas (FM AIS)
G1A Basic version, AIS NI Cl. I-III Div. 1&2, Group A-G
G1B 3 optocouplers (Chemoclean), AIS NI Cl. I-III Div. 1&2, Group A-G
G1D 3 optocouplers / feedback/hold contact (Autoclean), remote MR switching,
AIS NI Cl. I-III Div. 1&2, Group A-G
G1G feedback/hold contact, remote MR switching, PROFIBUS
AIS NI Cl. I-III Div. 1&2, Group A-G
2-circuit version for Ex areas (FM AIS)
G2B 3 optocouplers (Chemoclean), AIS NI Cl. I-III Div. 1&2, Group A-G
(p.t.o.)
®
®
, EEx em [ia/ib] IIC T4
®
, EEx em [ia/ib] IIC T4
, EEx em [ia/ib] IIC T4
Instrument description
®
®
®
®
, EEx em [ia/ib] IIC T4
®
,
®
,
®
