25. Move Tab
boundary limit is visualized with a spherical cone together with a vector indicating the current
orientation of the robot tool. The inside of the cone represents the allowed area for the tool
orientation (vector).
When the robot TCP is no longer in proximity of the limit, the 3D representation disappears. If the
TCP is in violation or very close to violating a boundary limit, the visualization of the limit turns red.

25.2.1. Feature

Under Feature, you can define how to control the robot arm relative to View, Base or Tool features.
For the best feel for controlling the robot arm you can select the View feature, then use Rotate
arrows to change the viewing angle of the 3D image to match your view of the real robot arm.

25.2.2. Active TCP

In the Robot field, under Active TCP, the name of the current active Tool Center Point (TCP) is
displayed.

25.2.3. Home

The Home button accesses the Move Robot into Position screen, where you can hold down the
Auto button (see
22.4.2. Move robot to: on
page 141) to move robot into position previously
defined under Installation (see
24.13.1. Defining Home on
page 219). The Home button's default
setting returns the Robo Arm to an upright position (see
24.13. Home on
page 219).

25.2.4. Freedrive

The on-screen Freedrive button allows the Robot Arm to be pulled into desired positions/poses.

25.2.5. Align

The Align button allows the Z axis of the active TCP to align to a selected feature.

25.3. Tool Position

The text boxes display the full coordinate values of the TCP relative to the selected feature. You
can configure several named TCPs
(see 24.2. TCP Configuration on
page 205). You can also tap
Edit pose to access the Pose Editor screen.

25.4. Joint Position

The Joint Position field allows you to directly control individual joints. Each joint moves along a
default joint limit range from − 360
to + 360
, defined by a horizontal bar. Once the limit is
reached you cannot move a joint any further. You can configure joints with a position range
different from the default (see
21.10. Joint Limits on
page 124), this new range is indicated with
red zone inside the horizontal bar.
UR5e
240
User Manual
