Field Replaceable Units
FRU Removal and Replacement
I/O Board
Before removing the I/O board, perform the following
procedures:
•
If you are replacing the original I/O board with a new
one, refer to the section, "Determining LAN ID and
FDDI ID" below before removing the board.
•
Remove the Main Tray Assembly
•
Remove all of the PCI, EISA, and GSC option boards
•
Remove the Rear Panel
146
